Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
61
MDX-CA680/CA680X
R519 1-216-809-11 METAL CHIP 100 5% 1/16W
R520 1-216-809-11 METAL CHIP 100 5% 1/16W
R521 1-216-809-11 METAL CHIP 100 5% 1/16W
R522 1-216-821-11 METAL CHIP 1K 5% 1/16W
R523 1-216-821-11 METAL CHIP 1K 5% 1/16W
R524 1-216-821-11 METAL CHIP 1K 5% 1/16W
R525 1-216-845-11 METAL CHIP 100K 5% 1/16W
R526 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R527 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R528 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R530 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R531 1-216-845-11 METAL CHIP 100K 5% 1/16W
R532 1-216-809-11 METAL CHIP 100 5% 1/16W
R533 1-216-845-11 METAL CHIP 100K 5% 1/16W
R534 1-216-845-11 METAL CHIP 100K 5% 1/16W
R535 1-216-845-11 METAL CHIP 100K 5% 1/16W
R537 1-216-809-11 METAL CHIP 100 5% 1/16W
R538 1-216-845-11 METAL CHIP 100K 5% 1/16W
R539 1-216-845-11 METAL CHIP 100K 5% 1/16W
R540 1-216-845-11 METAL CHIP 100K 5% 1/16W
R542 1-216-845-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB503 1-233-412-11 RES, CHIP NETWORK 1K (3216)
< THERMISTOR >
TH501 1-810-421-11 THERMISTOR NTH5G36B103K01TE
< VIBRATOR >
X301 1-795-144-21 OSCILLATOR, CERAMIC (45MHz)
X501 1-760-365-11 VIBRATOR, CERAMIC (10MHz)
**************************************************************
* 1-680-042-11 SUB BOARD
**********
1-792-195-11 CABLE, FLEXIBLE FLAT (14 CORE)
* 3-039-443-11 SHEET (CONNECTOR)
< CAPACITOR >
C814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP810 1-794-064-12 SOCKET, CONNECTOR 14P
< DIODE >
D810 8-719-056-83 DIODE UDZ-TE-17-6.8B
D817 8-719-056-93 DIODE UDZ-TE-17-18B
D818 8-719-056-83 DIODE UDZ-TE-17-6.8B
D821 8-719-056-83 DIODE UDZ-TE-17-6.8B
< LED >
LED810 8-719-082-38 LED CL-270SR-C-TS
(DISC SLOT ILLUMINATION) (CA680X)
LED810 8-719-082-40 LED CL-270FG-C-TS
(DISC SLOT ILLUMINATION) (CA680)
< SWITCH >
LSW810 1-771-883-11 SWITCH, TACTILE (WITH LED) (Z) (CA680X)
LSW810 1-786-113-11 SWITCH, TACT (WITH LED) (Z) (CA680)
***********************************************************
MISCELLANEOUS
**************
22 1-792-195-11 CABLE, FLEXIBLE FLAT (14 CORE)
24 1-776-207-82 CORD (WITH CONNECTOR) (POWER) (US)
24 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)
(AEP, UK)
64 1-694-780-11 CONDUCTIVE BOARD, CONNECTION
153 1-757-311-11 CABLE, FLEXIBLE FLAT (11 CORE)
0 165 8-583-065-03 OPTICAL PICK-UP KMS-241C/J1RP
CNP810 1-794-064-11 SOCKET, CONNECTOR 14P
LCD901 1-804-295-11 DISPLAY PANEL, LIQUID CRYSTAL (CA680)
LCD901 1-804-295-21 DISPLAY PANEL, LIQUID CRYSTAL (CA680X)
M901 A-3301-407-A MOTOR ASSY, SP (SPINDLE)
M902 A-3291-190-A MOTOR ASSY, SL (SLED)
M903 X-3379-451-1 MOTOR ASSY, LO (LOADING)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-792-09 SCREW +PTT 2.6X6 (S)
#2 7-621-772-20 SCREW +B 2X5
#3 7-627-553-28 SCREW, PRECISION +P 2X2.5
#4 7-685-790-01 SCREW +PTT 2.6X4 (S)
#5 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#6 7-685-793-09 SCREW +PTT 2.6X8 (S)
#7 7-685-794-09 SCREW +PTT 2.6X10 (S)
#8 7-685-797-09 SCREW +PTT 2.6X16 (S)
#9 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT
#11 7-685-851-04 SCREW +BVTT 2X4 (S)
#12 7-624-102-04 STOP RING 1.5, TYPE-E
#13 7-627-852-37 PRECISION SCREW +P1.7X1.8 TYPE3
#14 7-621-772-08 SCREW +B 2X3
#15 7-621-555-10 SCREW +K 2X3
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-227-351-11 MANUAL, INSTRUCTION (ENGLISH)
(CA680X: US)
3-227-352-11 MANUAL, INSTRUCTION, INSTALL
(ENGLISH, FRENCH) (CA680X: US)
3-227-353-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, DUTCH, ITALIAN)
(CA680/CA680X: AEP, UK)
3-227-354-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
FRENCH, GERMAN, DUTCH, ITALIAN)
(CA680/CA680X: AEP, UK)
X-3378-490-1 CASE (PANEL) ASSY (for FRONT PANEL)
************************************************************
SERVO SUB
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
