MV-700HR
13
3-8. LIQUID CRYSTAL DISPLAY PANEL (LCD900)
1
screw
(BTP 2
×
6)
2
retainer (LCD)
3
cushion (LCD)
4
liquid crystal display pane
l
(LCD900)
