60
MV-700HR
SECTION 8
ELECTRICAL PARTS LIST
CONTROL
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1111-883-A CONTROL BOARD, COMPLETE
*************************
< CAPACITOR >
C413 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
< DIODE >
D418 8-719-017-62 DIODE MA8068-L-TX
< IC >
IC404 6-600-439-01 IC NJL21H400AF3-M
< COIL >
L402 1-412-955-11 INDUCTOR 22uH
< TRANSISTOR >
Q406 8-729-905-35 TRANSISTOR 2SC4081-R
< RESISTOR >
R475 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R476 1-216-837-11 METAL CHIP 22K 5% 1/10W
************************************************************
A-1111-887-A MAIN BOARD, COMPLETE (US, CND)
A-1112-960-A MAIN BOARD, COMPLETE (AEP, UK, RU)
A-1113-033-A MAIN BOARD, COMPLETE (E (PAL), TW, AUS)
A-1113-062-A MAIN BOARD, COMPLETE (E (NTSC))
A-1118-865-A MAIN BOARD, COMPLETE (KR)
A-1118-875-A MAIN BOARD, COMPLETE (CH)
*********************
< CAPACITOR >
C101 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C102 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C103 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C104 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C105 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C106 1-164-813-11 CERAMIC CHIP 15PF 2% 50V
C107 1-164-813-11 CERAMIC CHIP 15PF 2% 50V
C108 1-164-813-11 CERAMIC CHIP 15PF 2% 50V
C109 1-164-813-11 CERAMIC CHIP 15PF 2% 50V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-113-642-11 TANTALUM CHIP 47uF 20% 10V
C114 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C117 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C120 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C121 1-104-852-11 TANTALUM CHIP 22uF 20% 10V
C122 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C128 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C129 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C135 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C136 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C137 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C138 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C139 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C141 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C142 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C143 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C144 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C145 1-104-851-11 TANTALUM CHIP 10uF 20% 10V
C146 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C147 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C148 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C149 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
AUS: Australian model
CH : Chinese model
CND : Canadian model
When indicating parts by reference
number, please include the board.
MAIN
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
Ver. 1.2
KR : Korean model
RU : Russian model
TW : Taiwan model
