MV-700HR
IC1101, 1201 TPA2005D1ZQYR
SHUTDOWN 1
NC
2
IN+
3
BIAS
CIRCUIT
+
–
IN– 4
PWM
H-
BRIDGE
INTERNAL
OSCILLATOR
7
VO+
6
GND
5
GND
8
VDD
VO–10
GND
11
GND
12
VDD
9
GND
13
GND
14
GND
15
IC1352 BA3121F
AMP
8
4
3
2
1
OUT1
VM1
IN1
GND
VCC
OUT2
VM2
IN2
AMP
7
6
5
IC1401 BD3872FS
32
SEQ1
31
SOUT1
100k
TREBLE1
fo = 10 kHz
TREBLE2
fo = 10 kHz
SURROUND
5
A1
16
GND
100k
6
A2
100k
7
B1
100k
8
B2
100k
9
C1
100k
10
C2
100k
11
D1
100k
12
D2
100k
13
E1
100k
14
E2
15
FILTER
4
SEL2
3
VIN2
2
SEL1
1
VIN1
LOUD
SPEAKER
EQUALIZER1
30
SEQ2
29
SOUT2
28
TNF1
27
TNF2
BASS1
fo = 80 Hz
BASS2
fo = 80 Hz
25
BOUT1
23
BOUT2
22
OUT1
21
OUT2
26
BNF1
24
BNF2
LOGIC
17
SC
18
SI
20
CAP
19
VCC
LOUD
SPEAKER
EQUALIZER2
IC1701 NJM2535V (TE2)
VIN1
CTL1
VIN2
4CTL2
BIAS
1
2
3
6 VCC
7 VOUT
75Ω
DRIVER
8 GND
5 VIN3
IC1702 NJM2561F1-TE2
1
POWER SAVE
2
VOUT
3
VSAG
6
VCC
5
GND
4
VIN
75 OHM
DRIVER
LOW-PASS
FILTER
CLAMP
