Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
72
MV-700HR
R810 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-821-11 METAL CHIP 1K 5% 1/10W
R812 1-216-821-11 METAL CHIP 1K 5% 1/10W
R813 1-216-821-11 METAL CHIP 1K 5% 1/10W
R814 1-216-821-11 METAL CHIP 1K 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-809-11 METAL CHIP 100 5% 1/10W
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R820 1-216-864-11 SHORT CHIP 0
R824 1-216-809-11 METAL CHIP 100 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R826 1-216-809-11 METAL CHIP 100 5% 1/10W
R827 1-216-809-11 METAL CHIP 100 5% 1/10W
R828 1-216-809-11 METAL CHIP 100 5% 1/10W
R829 1-216-809-11 METAL CHIP 100 5% 1/10W
R830 1-216-809-11 METAL CHIP 100 5% 1/10W
R831 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-864-11 SHORT CHIP 0
R833 1-216-841-11 METAL CHIP 47K 5% 1/10W
R834 1-216-809-11 METAL CHIP 100 5% 1/10W
R835 1-216-809-11 METAL CHIP 100 5% 1/10W
R836 1-216-821-11 METAL CHIP 1K 5% 1/10W
R837 1-216-809-11 METAL CHIP 100 5% 1/10W
R838 1-216-864-11 SHORT CHIP 0
R839 1-216-833-11 METAL CHIP 10K 5% 1/10W
R840 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R841 1-216-843-11 METAL CHIP 68K 5% 1/10W
R842 1-216-857-11 METAL CHIP 1M 5% 1/10W
R843 1-216-843-11 METAL CHIP 68K 5% 1/10W
R844 1-216-841-11 METAL CHIP 47K 5% 1/10W
R845 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R846 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R847 1-216-837-11 METAL CHIP 22K 5% 1/10W
R848 1-216-843-11 METAL CHIP 68K 5% 1/10W
R851 1-216-840-11 METAL CHIP 39K 5% 1/10W
R852 1-216-840-11 METAL CHIP 39K 5% 1/10W
R853 1-216-839-11 METAL CHIP 33K 5% 1/10W
R854 1-216-805-11 METAL CHIP 47 5% 1/10W
R855 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R856 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R857 1-216-842-11 METAL CHIP 56K 5% 1/10W
R858 1-216-805-11 METAL CHIP 47 5% 1/10W
R859 1-216-837-11 METAL CHIP 22K 5% 1/10W
R860 1-216-834-11 METAL CHIP 12K 5% 1/10W
R861 1-216-841-11 METAL CHIP 47K 5% 1/10W
R862 1-216-834-11 METAL CHIP 12K 5% 1/10W
R863 1-216-840-11 METAL CHIP 39K 5% 1/10W
R864 1-216-837-11 METAL CHIP 22K 5% 1/10W
R901 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R902 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R903 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R904 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R905 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R910 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R920 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R921 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R923 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV801 1-225-905-21 RES, ADJ, CERMET (3 TYPE) 47K
RV851 1-225-905-21 RES, ADJ, CERMET (3 TYPE) 47K
< SWITCH >
S401 1-786-860-11 SWITCH, TACTILE (S-MENU)
S402 1-786-860-11 SWITCH, TACTILE (VOLUME –)
S403 1-786-860-11 SWITCH, TACTILE (VOLUME +)
S404 1-786-860-11 SWITCH, TACTILE (SOURCE)
S406 1-786-860-11 SWITCH, TACTILE (u)
S407 1-786-860-11 SWITCH, TACTILE (x)
S408 1-786-860-11 SWITCH, TACTILE (.)
S409 1-786-860-11 SWITCH, TACTILE (>)
S412 1-786-860-11 SWITCH, TACTILE (POWER)
S413 1-786-175-31 SWITCH, TACTILE (RESET)
< TRANSFORMER >
T1033 1-443-763-11 TRANSFORMER, INVERTER
< VIBRATOR >
X401 1-795-427-21 VIBRATOR, CERAMIC (4.19MHz)
X402 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
X701 1-767-104-21 VIBRATOR, CRYSTAL (3.58MHz)
X702 1-813-108-11 QUARTZ CRYSTAL UNIT (4.43MHz)
************************************************************
MISCELLANEOUS
**************
3 X-2022-450-1 WIRE (ANTENNA) ASSY
(US, CND, E (PAL), TW, KR, AUS, CH)
4 1-829-358-21 CORD, CONNECTION (CIGAR)
(US, CND, AEP, UK, RU)
5 1-829-358-31 CORD, CONNECTION (CIGAR) (E (NTSC))
06 1-468-626-52 ADAPTOR, AC (MPA-AC1)
7 1-469-241-11 CORE, FERRITE (RFC-8 BK)
(US, CND, AEP, UK, RU)
8 1-765-080-91 CORD, CONNECTION (AUDIO/VIDEO CABLE)
(E (NTSC))
8 1-824-097-11 CORD, CONNECTION
(AUDIO/VIDEO INPUT CABLE)
(US, CND, E (PAL), TW, KR, AUS, CH)
9 A-1121-886-A CRADLE ASSY
(US, CND, AEP, UK, RU, E (NTSC))
010 1-829-237-11 CORD, POWER (for AC ADAPTOR)
(US, CND, E (NTSC))
011 1-827-480-11 POWER-SUPPLY CORD (for AC ADAPTOR)
(AEP, UK)
012 1-827-481-11 POWER-SUPPLY CORD (for AC ADAPTOR)
(AEP, UK, RU, E (PAL), AUS)
013 1-776-985-12 CORD, POWER (KR)
014 1-827-947-31 CORD, POWER (CH)
015 1-830-518-11 POWER-SUPPLY CORD SET (TW)
201 1-863-494-12 FLEXIBLE (MS) BOARD
202 1-817-116-11 CONNECTOR, MEMORY STICK
0212 1-479-344-11 OPTICAL PICK-UP BLOCK (SDR-085T)
251 A-1111-891-A CONNECTION (UNIT) (121) ASSY (XA-121)
(E (PAL), TW, KR, AUS, CH)
MONITOR
Ver. 1.2
