Chapter 12 Setup Menus
12-30 Chapter 12 Setup Menus
12-4 Items in the Extended Setup Menu
Menu items in the range 800 to 899, relating to audio control (Continued)
Item number
Item name
Settings
827 AES OUT SEL Select the audio signals to assign to AES/EBU audio output channels.
Note
Check to be sure that the selected tracks are being output from the AES/EBU
OUTPUT connectors.
Sub-item
1 CH1/CH2 tr1/2 : Assign tracks 1, 2 to output channels 1, 2.
tr3/4: Assign tracks 3, 4 to output channels 1, 2.
tr5/6: Assign tracks 5, 6 to output channels 1, 2.
tr7/8: Assign tracks 7, 8 to output channels 1, 2.
2 CH3/CH4 tr1/2: Assign tracks 1, 2 to output channels 3, 4.
tr3/4 : Assign tracks 3, 4 to output channels 3, 4.
tr5/6: Assign tracks 5, 6 to output channels 3, 4.
tr7/8: Assign tracks 7, 8 to output channels 3, 4.
828 SDI OUT SEL Select the audio signals to assign to SDI audio output channels.
The HD-SDI OUTPUT connector of the UP-CONTROL option also follows this
menu item.
Note
Check to be sure that the selected tracks are being output from the SDI OUTPUT
connectors.
Sub-item
1 CH1/CH2 tr1/2 : Assign tracks 1, 2 to output channels 1, 2.
tr3/4: Assign tracks 3, 4 to output channels 1, 2.
tr5/6: Assign tracks 5, 6 to output channels 1, 2.
tr7/8: Assign tracks 7, 8 to output channels 1, 2.
2 CH3/CH4 tr1/2: Assign tracks 1, 2 to output channels 3, 4.
tr3/4 : Assign tracks 3, 4 to output channels 3, 4.
tr5/6: Assign tracks 5, 6 to output channels 3, 4.
tr7/8: Assign tracks 7, 8 to output channels 3, 4.
829 SDTI OUT SEL Select the audio signals to assign to SDTI audio output channels.
Note
Check to be sure that the selected tracks are being output from the SDTI
OUTPUT connectors.
Sub-item
1 CH1/CH2 tr1/2 : Assign tracks 1, 2 to output channels 1, 2.
tr3/4: Assign tracks 3, 4 to output channels 1, 2.
tr5/6: Assign tracks 5, 6 to output channels 1, 2.
tr7/8: Assign tracks 7, 8 to output channels 1, 2.
2 CH3/CH4 tr1/2: Assign tracks 1, 2 to output channels 3, 4.
tr3/4 : Assign tracks 3, 4 to output channels 3, 4.
tr5/6: Assign tracks 5, 6 to output channels 3, 4.
tr7/8: Assign tracks 7, 8 to output channels 3, 4.
