Sony MXD-D4 - CD Section Test Modes; CD Command Transfer and Error Display Tests; CD Speed, Check 8, Port, and Servo Tests

31
CD SECTION
Set the CD test mode when performing confirmations (refer to page 10).
After completing confirmation, release the CD test mode.
1. COMMAND TRANSFER MENU
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “0> COMMAND”, and press the [ AMS ] (MD)
knob.
(2) Select a command with [ AMS ] (MD) knob, and press the [ AMS ] (MD) knob to set.
(3) Select the edit position with m (MD) and M (MD) buttons, and rotate [ AMS ] (MD) knob for editing, then press the
[ AMS ] (MD) knob for transfer.
(4) To exit from this mode, press the [MENU/NO] button.
2. C1, C2 ERROR DISPLAY
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “1> ERROR”, and press the [ AMS ] (MD) knob.
(2) C1 error and C2 error are displayed on the left side and right side with 4-digit codes respectively.
(3) To exit from this mode, press the [MENU/NO] button.
3. DISC SPEED SELECTION
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “2> SPEED ×1”, and press the [ AMS ] (MD) knob.
(2) Each time the [ AMS ] (MD) knob is pressed, the speed changes over such as ×1 t ×2 t ×4 t ×1.
(3) To exit from this mode, press the [MENU/NO] button.
4. CHECK 8 DISPLAY
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “4> CHECK 8”, and press the [ AMS ] (MD) knob.
(2) The time from spindle kick to GFS detect is displayed.
(3) To exit from this mode, press the [MENU/NO] button.
5. PORT SELECTION
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “7> PORT”, and press the [ AMS ] (MD) knob.
(2) Rotate the [ AMS ] (MD) knob to select GFS, ERROR RATE, RFCK and press the [ AMS ] (MD) knob to set.
(3) To exit from this mode, press the [MENU/NO] button.
6. AMS ON/OFF
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “8> AMS ON”, and press the [ AMS ] (MD) knob.
(2) Switch the high speed ON/OFF of the track jamp.
(3) To exit from this mode, press the [MENU/NO] button.
7. TRK ON/OFF
Procedure:
(1) Enter the test mode, then rotate [ AMS ] (MD) knob to display “9> TRK ON”, and press the [ AMS ] (MD) knob.
(2) Switch the tracking servo ON/OFF.
(3) To exit from this mode, press the [MENU/NO] button.
