Sony MXD-D4 - Electrical Parts List (Continued); LP LED, HP, LF, and TRANS Board Component Lists

89
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DISPLAY HP LF LOADING LP LED MAIN
S732 1-762-875-21 SWITCH, KEYBOARD (YES)
S733 1-762-875-21 SWITCH, KEYBOARD (MENU NO)
S734 1-762-875-21 SWITCH, KEYBOARD (HIGH CD SYNCHRO)
S735 1-762-875-21 SWITCH, KEYBOARD (NORMAL CD SYNCHRO)
S736 1-762-875-21 SWITCH, KEYBOARD (A OPEN/CLOSE)
S741 1-762-875-21 SWITCH, KEYBOARD (x (MD))
S742 1-762-875-21 SWITCH, KEYBOARD (X (MD))
S743 1-762-875-21 SWITCH, KEYBOARD (G (MD))
S744 1-762-875-21 SWITCH, KEYBOARD (M (MD))
S745 1-762-875-21 SWITCH, KEYBOARD (z REC)
S746 1-762-875-21 SWITCH, KEYBOARD (A EJECT)
**************************************************************
HP BOARD
*********
< CAPACITOR >
C359 1-162-290-31 CERAMIC 470PF 10% 50V
C360 1-164-159-11 CERAMIC 0.1uF 50V
C361 1-162-290-31 CERAMIC 470PF 10% 50V
< JACK >
J301 1-770-306-11 JACK (LARGE TYPE) (PHONES) (BLACK)
J301 1-770-307-11 JACK (LARGE TYPE) (PHONES)
(Singapore: GOLD)
< FERRITE BEAD >
L311 1-410-397-21 FERRITE BEAD INDUCTOR
L312 1-410-397-21 FERRITE BEAD INDUCTOR
L313 1-410-397-21 FERRITE BEAD INDUCTOR
< RESISTOR >
R309 1-249-393-11 CARBON 10 5% 1/4W
R310 1-249-393-11 CARBON 10 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-225-882-11 RES, VAR, CARBON 20K/20K (PHONE LEVEL)
**************************************************************
LF BOARD (Singapore)
*********
< CAPACITOR >
0C798 1-113-925-11 CERAMIC 0.01uF 20% 250V
(Singapore)
0C799 1-113-925-11 CERAMIC 0.01uF 20% 250V
(Singapore)
< CONNECTOR >
* CN798 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P (Singapore)
CN799 1-769-745-21 LEAD (WITH CONNECTOR) (2 CORE)
(Singapore)
< LINE FILTER >
0LF798 1-411-547-11 FILTER, LINE (Singapore)
**************************************************************
1-674-336-21 LOADING BOARD
***************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE) (IN/OUT DETECT)
**************************************************************
LP LED BOARD
*************
< DIODE >
D791 8-719-046-39 LED SEL5821A-TP15 (MDLP)
< RESISTOR >
R791 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S791 1-762-875-21 SWITCH, KEYBOARD (REC MODE)
**************************************************************
A-4725-387-A MAIN BOARD, COMPLETE (Singapore)
A-4725-395-A MAIN BOARD, COMPLETE (AEP, UK)
A-4725-402-A MAIN BOARD, COMPLETE (US, Canadian)
*********************
* 3-309-144-21 HEAT SINK
* 4-941-237-11 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
< CAPACITOR/SHORT >
C100 1-128-551-11 ELECT 22uF 20% 25V
C101 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C102 1-115-417-11 CERAMIC CHIP 2700PF 5% 25V
C103 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C104 1-128-551-11 ELECT 22uF 20% 25V
C105 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C106 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C107 1-128-551-11 ELECT 22uF 20% 25V
C108 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-128-551-11 ELECT 22uF 20% 25V
C200 1-128-551-11 ELECT 22uF 20% 25V
C201 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C202 1-115-417-11 CERAMIC CHIP 2700PF 5% 25V
C203 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C204 1-128-551-11 ELECT 22uF 20% 25V
C205 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C206 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C207 1-128-551-11 ELECT 22uF 20% 25V
C208 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-128-551-11 ELECT 22uF 20% 25V
C300 1-126-933-11 ELECT 100uF 20% 16V
C301 1-126-933-11 ELECT 100uF 20% 16V
C302 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C304 1-165-319-11 CERAMIC CHIP 0.1uF 50V
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
