Sony MXD-D4 - Electrical Parts List (Continued); PW SW Board Component List

93
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R850 1-216-073-00 METAL CHIP 10K 5% 1/10W
R864 1-216-295-11 SHORT 0
< COMPOSITION CIRCUIT BLOCK >
RB800 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
RB801 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
RB802 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
RB803 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
RB804 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
RB805 1-233-710-21 RES, NETWORK (3216) 1.5K
RB806 1-236-908-11 NETWORK RESISTOR (CHIP) 10K
< VARIABLE RESISTOR >
RV500 1-225-895-21 RES, ADJ, CERMET (3 TYPE) 1K
< VIBRATOR >
X800 1-579-930-12 VIBRATOR, CERAMIC (16MHz)
X801 1-795-004-21 VIBRATOR, CERAMIC (10MHz)
**************************************************************
TRANS BOARD
*************
< CAPACITOR >
0C601 1-113-920-11 CERAMIC 0.0022uF 20% 250V
(Singapore)
0C651 1-113-920-11 CERAMIC 0.0022uF 20% 250V
(EXCEPT Singapore)
0C652 1-113-925-11 CERAMIC 0.01uF 20% 250V
(EXCEPT Singapore)
0C653 1-113-925-11 CERAMIC 0.01uF 20% 250V
(EXCEPT Singapore)
< CONNECTOR >
CN602 1-564-321-00 PIN, CONNECTOR 2P (Singapore)
CN652 1-564-321-00 PIN, CONNECTOR 2P (EXCEPT Singapore)
< DIODE >
0D600 8-719-200-02 DIODE 11E2-TB2 (Singapore)
0D651 8-719-200-02 DIODE 11E2-TB2 (EXCEPT Singapore)
< LINE FILTER >
0LF651 1-411-547-11 FILTER, LINE (EXCEPT Singapore)
< RELAY >
0RY600 1-755-245-11 RELAY, AC POWER (Singapore)
0RY650 1-755-245-11 RELAY, AC POWER (EXCEPT Singapore)
< SWITCH >
0S600 1-771-474-11 SWITCH, POWER (VOLTAGE SELECTER)
(Singapore)
< TRANSFORMER >
0T601 1-435-650-11 TRANSFORMER, POWER (Singapore)
0T602 1-435-691-11 TRANSFORMER, POWER (Singapore)
0T651 1-435-648-11 TRANSFORMER, POWER (US, Canadian)
0T651 1-435-649-11 TRANSFORMER, POWER (AEP, UK)
0T652 1-433-666-11 TRANSFORMER, POWER (US, Canadian)
0T652 1-433-668-11 TRANSFORMER, POWER (AEP, UK)
**************************************************************
PW SW BOARD
*************
< CAPACITOR >
C781 1-124-584-00 ELECT 100uF 20% 10V
C782 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN703 1-691-746-11 CONNECTOR, BOARD TO BOARD 5P
< DIODE >
D781 8-719-301-39 LED SEL2210S-D-TP (STANDBY)
< IC >
IC781 8-749-011-05 IC GP1U28X ( )
< TRANSISTOR >
Q781 8-729-900-65 TRANSISTOR UN4113-TA
< RESISTOR >
R781 1-247-807-31 CARBON 100 5% 1/4W
R782 1-247-807-31 CARBON 100 5% 1/4W
R783 1-249-411-11 CARBON 330 5% 1/4W
< SWITCH >
S708 1-762-875-21 SWITCH, KEYBOARD (l/1)
**************************************************************
MISCELLANEOUS
**************
2 1-792-812-11 WIRE (FLAT TYPE) (27 CORE)
3 1-792-817-11 WIRE (FLAT TYPE) (17 CORE)
5 1-792-818-11 WIRE (FLAT TYPE) (21 CORE)
56 1-792-953-11 WIRE (FLAT TYPE) (18 CORE)
103 1-569-972-21 SOCKET, SHORT 2P
0108 1-777-071-21 CORD, POWER (AEP)
0108 1-777-071-41 CORD, POWER (Singapore)
0108 1-783-820-11 CORD, POWER (US, Canadian)
0108 1-790-226-11 CORD, POWER (UK)
357 1-678-514-11 FLEXIBLE BOARD
0358 A-4672-976-A OPTICAL PICK-UP KMS-262A/J1N
0517 A-4677-295-A BU-21BD53
HR901 1-500-670-11 HEAD, OVER WRIGHT
M101 A-4735-029-A MOTOR ASSY, SPINDLE (for MD)
M102 A-4672-900-A MOTOR ASSY, SLED (for MD)
M103 A-4672-975-A MOTOR ASSY, LOADING (for MD)
M201 A-4672-984-A MOTOR (LD) ASSY
S102 1-771-957-11 SWITCH, PUSH (2 KEY)
(REFLECT RATE DETECT, PROTECT DETECT)
0T601 1-435-650-11 TRANSFORMER, POWER (Singapore)
0T651 1-435-648-11 TRANSFORMER, POWER (US, Canadian)
0T651 1-435-649-11 TRANSFORMER, POWER (AEP, UK)
************************************************************
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN TRANS PW SW
