27
MZ-E10
50 XSLP MTR OP O Start/stop signal output to motor drive (CXA8125ER-TBM-E)
51 XDISC DET I Not used (connected to ground)
52 D_EN2 O Drive control signal output to Headphone AMP (NJU-8713V-TE2)
53 to 56 SMON 0 to 3 – Not used (open)
57 F16M O Clock (16.9344MHz) output to Headphone AMP (NJU-8713V-TE2)
58 to 61 MD 7 to 4 – Not used (open)
62 VCC2 – Power supply
63 MD3 – Not used (open)
64 MECNT0 I Not used (open)
65 MECNT1 – Not used (open)
66 FG I Spindle FG signal input from motor drive (CXA8125ER-TBM-E)
67 MD2 – Not used (open)
68 4M O Clock output to motor drive (CXA8125ER-TBM-E)
69 MD1 – Not used (open)
70 MD0 – Not used (open)
71 TRPWMF O Tracking PWM signal output to motor drive (CXA8125ER-TBM-E)
72 TRPWMR O Tracking PWM signal output to motor drive (CXA8125ER-TBM-E)
73 FOPWMF O Focus PWM signal output to motor drive (CXA8125ER-TBM-E)
74 FOPWMR O Focus PWM signal output to motor drive (CXA8125ER-TBM-E)
75 SPPWMF O Spindle PWM signal output to motor drive (CXA8125ER-TBM-E)
76 SPPWMR O Spindle PWM signal output to motor drive (CXA8125ER-TBM-E)
77 VSS – Ground
78 VCC2 – Power supply
79 VDD – Power supply
80 SLPWMF O Sled PWM signal output to motor drive (CXA8125ER-TBM-E)
81 SLPWMR O Sled PWM signal output to motor drive (CXA8125ER-TBM-E)
82 SLD0 O Sled stepping control signal output to motor drive (CXA8125ER-TBM-E)
83 SLD1 I Sled FG signal input from motor drive (CXA8125ER-TBM-E)
84 SLD2 O Sled control signal output to motor drive (CXA8125ER-TBM-E)
85 SLD3 O Stepping /DC change signal output to motor drive (CXA8125ER-TBM-E)
86 (LOCAL CHK3) – Not used (open)
87 VSS – Ground
88 HOLD SW I HOLD switch signal input
89 MD15 – Not used
90 MD14 – Not used
91 XADJUST I Test mode set input
92 XPATCH I Not used (connected to ground)
93 MD13 – Not used (open)
94 TYPE3 I Not used (connected to ground)
95 MD12 – Not used (open)
96 TYPE2 I Not used (connected to ground)
97 VSS – Ground
98 to 101 MD11 to 8 – Not used (open)
102 TYPE1 I Not used (connected to ground)
103 TYPE0 I Not used (open)
104 LDREF O Laser control signal output to RF AMP (SN761058ZQL)
105 VSS – Ground
106 XIN I System clock input (16.9344MHz)
107 XOUT O System clock output (16.9344MHz)
108 VDD – Power supply
109 DPVSS – Ground
DescriptionPin Name
Pin No.
I/O
