Sony MZ-E10 - Control Board Disassembly; Optical Pick-up Assembly Disassembly

7
MZ-E10
3-5. CONTROL BOARD
7 CONTROL board
Bracket ASSY
6 Button (control)
4 Cover (control)
3 Knob (open)
1 Screw (M1.4)
2 Remove three claws
5 Switch flexible board
(CN801)
3-6. OPTICAL PICK-UP ASSY (ABX-1ES)
5
2 Gear (SA)
Mechanism deck
(MT-MZE10-184)
1 Washer (0.8-2.5)
4 Spring, thrust detent
3 Screw, tapping
6 Optical pick-up ASSY
(ABX-1ES)
