35
MZ-E10
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
• Abbreviation
CND : Canadian
HK : Hong Kong
JEW : Tourist
KR : Korean
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
* A-3178-957-A MAIN BOARD ASSY
**************
1-686-494-11 POWER RELAY FLEXIBLE BOARD
< CAPACITOR >
C101 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C102 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C104 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C201 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C202 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C204 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C301 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C302 1-137-858-11 TANTAL. CHIP 47uF 20% 6.3V
C303 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C304 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C305 1-137-701-11 TANTAL. CHIP 4.7uF 20% 10V
C306 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C307 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C308 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-137-859-11 TANTAL. CHIP 220uF 20% 4V
C311 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C312 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V
C501 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V
C502 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V
C503 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C505 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C506 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C508 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C509 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C510 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C511 1-137-762-91 TANTALUM 10uF 20% 4V
C512 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C513 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C515 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C518 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C519 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C520 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C523 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C525 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C526 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C527 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C532 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C533 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C534 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C535 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C536 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C551 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C552 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C553 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C554 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C555 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C556 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C557 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C558 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C603 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C605 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C607 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C608 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C609 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C610 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C611 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C612 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C613 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C614 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C616 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C617 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C618 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C619 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C620 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C621 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C622 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C626 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C628 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C801 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C803 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C804 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C805 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C851 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C852 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C901 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
