3
MZ-E10
SECTION 1
SER
VICING NO
TE
When repairing this device with the power on, if you remove the main board, this device stops working.
In this case, you work without the device stopping by fastening the hook of the Open/Close detection switch (S803).
Open/Close detection s
witch (S803)
2
4
Table of Contents
Specifications
1
Table of Contents
2
1 Servicing Note
3
2 General
4
Playing an MD
4
3 Disassembly
5
Panel Assy (S), Upper
5
Mechanism Deck (MT-MZE10-184)
5
Bracket Assy
6
Power Board, Main Board
6
Control Board
7
Optical Pick-Up Assy(ABX-1ES)
7
4 Test Mode
8
5 Electrical Adjustments
11
6 Diagrams
19
Block Diagram
19
Printed Wiring Boards - Main Section (1/2)
20
Printed Wiring Boards - Main Section (2/2)
21
Schematic Diagram - Main Section (1/3)
22
Schematic Diagram - Main Section (2/3)
23
Schematic Diagram - Main Section (3/3)
24
IC Pin Function Descrintion
26
IC Block Diagrams
30
7 Exploded Views
33
Main Section
33
Mechanism Deck Section (MT-MZE10-184)
34
8 Electrical Parts List
35
