Sony MZ-E10 - Bracket Assembly Disassembly; Power and Main Board Removal

6
MZ-E10
3-3. BRACKET ASSY
3-4. POWER BOARD, MAIN BOARD
8
3
7 Two screws (M1.4)
1 Screw (M1.4)
4 Lid (DC), battery case
5 Konb (power)
9 Switch flexible board
(CN801)
6 Screw (M1.4)
0 Bracket ASSY
Sheet (blind)
2 Plate, retainer
6
1 Case, battery
3 Battery, lithium ion storage
2 Retainer, battery
4 POWER board
5 Power relay flexible board
(CN952, CN953)
7 MAIN board ASSY
