Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
@ Replacement of IC501 and IC601 used in this set requires a
special tool.
C902 1-135-837-91 TANTAL. CHIP 22uF 20% 6.3V
C903 1-135-837-91 TANTAL. CHIP 22uF 20% 6.3V
C904 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C905 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C906 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C907 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C908 1-137-858-11 TANTAL. CHIP 47uF 20% 6.3V
C909 1-100-396-91 TANTAL. CHIP 4.7uF 20% 16V
C910 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C911 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C912 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C913 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C915 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C916 1-100-352-91 CHIP CERAMIC 1uF 16V
C917 1-135-837-91 TANTAL. CHIP 22uF 20% 6.3V
C920 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C921 1-100-352-91 CHIP CERAMIC 1uF 16V
C922 1-165-799-11 TANTAL. CHIP 22uF 20% 4V
C923 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C924 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C925 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C926 1-135-837-91 TANTAL. CHIP 22uF 20% 6.3V
C928 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C929 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C951 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
C952 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C953 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C954 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C955 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C956 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C957 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C958 1-100-352-91 CHIP CERAMIC 1uF 16V
C959 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C960 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN801 1-816-846-21 CONNECTOR, FPC (ZIF)
CN951 1-816-868-21 CONNECTOR (POWER JACK)
CN952 1-816-922-21 CONNECTOR, FPC (ZIF)
< DIODE >
D101 8-719-056-58 DIODE MAZS027008SO
D201 8-719-056-58 DIODE MAZS027008SO
D301 8-719-056-58 DIODE MAZS027008SO
D801 6-500-444-01 DIODE TLRE1008A(T04) (GROUP)
D802 6-500-445-01 DIODE TLOE1008A(T04) (GROUP)
D803 6-500-446-01 DIODE TLGE1008A(T04) (GROUP)
D851 8-719-077-43 DIODE MAZZ068H01S0
D902 8-719-420-51 DIODE MA729
D903 8-719-071-45 DIODE MA116-(TX).SO
D904 8-719-071-45 DIODE MA116-(TX).SO
D951 6-500-369-01 DIODE FT1J3TP
< FERRITE BEAD >
FB101 1-216-864-11 METAL CHIP 0 5% 1/10W
FB201 1-216-864-11 METAL CHIP 0 5% 1/10W
FB601 1-414-227-11 FERRITE 0uH
FB801 1-414-228-11 FERRITE 0uH
FB802 1-414-228-11 FERRITE 0uH
FB803 1-469-082-21 FERRITE 0uH
< IC >
IC301 6-703-631-01 IC NJU8713V-TE2
IC302 6-703-652-01 IC LMV301MGX/NOPB
@ IC501 6-702-869-01 IC SN761058ZQL
IC551 8-835-792-01 IC CXA8125ER-TBM-E
@ IC601 6-802-226-01 IC LC896442-VH4-16-E
IC801 8-759-680-85 IC AK6417AL-L
IC901 6-702-865-01 IC SC901580EPR2
IC951 6-702-867-01 IC SC901582EPR2
IC952 8-759-824-57 IC XC61CN3002NR
< JACK >
J301 1-816-845-21 JACK 7P (i)
< COIL >
L101 1-412-032-11 INDUCTOR CHIP 100uH
L201 1-412-032-11 INDUCTOR CHIP 100uH
L501 1-469-570-21 INDUCTOR 10uH
L551 1-469-846-11 INDUCTOR 47uH
L552 1-400-353-21 INDUCTOR 22uH
L901 1-424-929-21 INDUCTOR 150uH
L902 1-412-033-11 INDUCTOR CHIP 220uH
L903 1-424-929-21 INDUCTOR 150uH
L904 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q102 8-729-050-32 TRANSISTOR 2SC5585TL
Q202 8-729-050-32 TRANSISTOR 2SC5585TL
Q301 6-550-376-01 TRANSISTOR UMX1N-TN
Q302 8-729-055-85 TRANSISTOR UMT1N-TN
Q303 6-550-527-01 TRANSISTOR NTHD5904T1
Q304 8-729-037-61 TRANSISTOR UN9113J-(TX).SO
Q501 8-729-922-10 TRANSISTOR 2SA1577-QR
Q802 8-729-427-49 TRANSISTOR XP4214-TXE
Q901 6-550-561-01 TRANSISTOR MMBF0202PLT1
Q902 6-550-561-01 TRANSISTOR MMBF0202PLT1
Q903 8-729-048-92 TRANSISTOR HAT1043M-EL
Q904 8-729-048-77 TRANSISTOR XP4313-(TX).SO
Q951 6-550-326-01 TRANSISTOR FZT968TA
Q952 8-729-037-61 TRANSISTOR UN9113J-(TX).SO
Q953 8-729-042-27 TRANSISTOR 2SD2216J-QR(TX).SO
< RESISTOR >
R102 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R104 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R202 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R204 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R301 1-218-965-11 RES-CHIP 10K 5% 1/16W
R302 1-218-969-11 RES-CHIP 22K 5% 1/16W
R303 1-218-965-11 RES-CHIP 10K 5% 1/16W
R304 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R305 1-218-965-11 RES-CHIP 10K 5% 1/16W
R306 1-218-941-81 RES-CHIP 100 5% 1/16W
R307 1-218-973-11 RES-CHIP 47K 5% 1/16W
R309 1-208-635-11 RES-CHIP 10 0.5% 1/16W
