37
MZ-E10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R310 1-218-990-11 SHORT CHIP 0
R311 1-218-953-11 RES-CHIP 1K 5% 1/16W
R312 1-218-969-11 RES-CHIP 22K 5% 1/16W
R313 1-218-953-11 RES-CHIP 1K 5% 1/16W
R315 1-218-937-11 RES-CHIP 47 5% 1/16W
R317 1-218-989-11 RES-CHIP 1M 5% 1/16W
R318 1-218-989-11 RES-CHIP 1M 5% 1/16W
R501 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R502 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R504 1-242-967-81 RES-CHIP 1 5% 1/16W
R505 1-218-977-11 RES-CHIP 100K 5% 1/16W
R506 1-218-990-11 SHORT CHIP 0
R507 1-218-990-11 SHORT CHIP 0
R509 1-218-990-11 SHORT CHIP 0
R510 1-218-965-11 RES-CHIP 10K 5% 1/16W
R511 1-218-965-11 RES-CHIP 10K 5% 1/16W
R513 1-218-990-11 SHORT CHIP 0
R514 1-218-990-11 SHORT CHIP 0
R516 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R518 1-218-990-11 SHORT CHIP 0
R551 1-218-977-11 RES-CHIP 100K 5% 1/16W
R552 1-218-965-11 RES-CHIP 10K 5% 1/16W
R553 1-218-973-11 RES-CHIP 47K 5% 1/16W
R554 1-243-975-81 METAL CHIP 4.7M 5% 1/16W
R561 1-216-801-11 METAL CHIP 22 5% 1/10W
R562 1-216-797-11 METAL CHIP 10 5% 1/10W
R563 1-216-801-11 METAL CHIP 22 5% 1/10W
R564 1-216-805-11 METAL CHIP 47 5% 1/10W
R601 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R602 1-218-973-11 RES-CHIP 47K 5% 1/16W
R603 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R605 1-218-989-11 RES-CHIP 1M 5% 1/16W
R606 1-218-990-11 SHORT CHIP 0
R607 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R608 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R609 1-218-965-11 RES-CHIP 10K 5% 1/16W
R610 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R611 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R613 1-218-949-11 RES-CHIP 470 5% 1/16W
R614 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R615 1-218-965-11 RES-CHIP 10K 5% 1/16W
R617 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R618 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R620 1-218-965-11 RES-CHIP 10K 5% 1/16W
R621 1-218-977-11 RES-CHIP 100K 5% 1/16W
R622 1-218-965-11 RES-CHIP 10K 5% 1/16W
R623 1-218-965-11 RES-CHIP 10K 5% 1/16W
R627 1-218-990-11 SHORT CHIP 0
R628 1-218-969-11 RES-CHIP 22K 5% 1/16W
R801 1-218-989-11 RES-CHIP 1M 5% 1/16W
R802 1-218-989-11 RES-CHIP 1M 5% 1/16W
R803 1-218-941-81 RES-CHIP 100 5% 1/16W
R804 1-218-941-81 RES-CHIP 100 5% 1/16W
R817 1-218-945-11 RES-CHIP 220 5% 1/16W
R818 1-244-161-81 RES-CHIP 2.2 5% 1/16W
R819 1-218-949-11 RES-CHIP 470 5% 1/16W
R901 1-218-985-11 RES-CHIP 470K 5% 1/16W
R902 1-218-981-11 RES-CHIP 220K 5% 1/16W
R903 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R904 1-218-981-11 RES-CHIP 220K 5% 1/16W
R905 1-218-953-11 RES-CHIP 1K 5% 1/16W
R906 1-218-989-11 RES-CHIP 1M 5% 1/16W
R908 1-218-965-11 RES-CHIP 10K 5% 1/16W
R909 1-218-953-11 RES-CHIP 1K 5% 1/16W
R911 1-218-977-11 RES-CHIP 100K 5% 1/16W
R912 1-218-965-11 RES-CHIP 10K 5% 1/16W
R914 1-218-990-11 SHORT CHIP 0
R915 1-218-990-11 SHORT CHIP 0
R916 1-218-985-11 RES-CHIP 470K 5% 1/16W
R917 1-218-981-11 RES-CHIP 220K 5% 1/16W
R918 1-218-981-11 RES-CHIP 220K 5% 1/16W
R919 1-218-989-11 RES-CHIP 1M 5% 1/16W
R921 1-218-990-11 SHORT CHIP 0
R951 1-218-990-11 SHORT CHIP 0
R952 1-218-973-11 RES-CHIP 47K 5% 1/16W
R953 1-218-973-11 RES-CHIP 47K 5% 1/16W
R955 1-218-989-11 RES-CHIP 1M 5% 1/16W
R956 1-245-454-21 METAL FILM (SMD) 0.022(1608)
R957 1-218-941-81 RES-CHIP 100 5% 1/16W
R958 1-218-965-11 RES-CHIP 10K 5% 1/16W
R959 1-245-456-21 METAL FILM (SMD) 1.0(1608)
R961 1-245-457-21 METAL FILM (SMD) 2.2(1608)
R964 1-218-941-11 METAL CHIP 100 0.5% 1/16W
R965 1-218-945-11 METAL CHIP 220 0.5% 1/16W
R967 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
< SWITCH >
S802 1-786-424-21 SWITCH, TACTILE (GROUP)
S803 1-786-443-21 SWITCH, DETECTION (OPEN/CLOSE)
S804 1-786-425-21 SWITCH, SLIDE (HOLD N )
< VIBRATOR >
X601 1-795-561-21 VIBRATOR, CERAMIC (16.9344MHz)
*****************************************************
*
A-3178-966-A POWER BOARD, COMPLETE
*********************
< CONNECTOR >
CN953 1-816-937-21 CONNECTOR, FPC (ZIF)
CN954 1-816-922-21 CONNECTOR, FPC (ZIF)
< SWITCH >
S901 1-786-425-21 SWITCH, SLIDE (BUILT-IN BATTERY)
******************************************************
* A-3178-965-A CONTROL BOARD, COMPLETE
**********************
< CONNECTOR >
CN802 1-816-846-21 CONNECTOR, FPC (ZIF)
< RESISTOR >
R811 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R812 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R813 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
POWER CONTROL
