MZ-E10
Ref. No. Part No. Description Remark
R814 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R815 1-218-965-11 RES-CHIP 10K 5% 1/16W
R816 1-218-965-11 RES-CHIP 10K 5% 1/16W
< SWITCH >
S801 1-786-401-21 SWITCH, TACTILE
(., > N, x, VOL–, VOL+)
******************************************************
MISCELLANEOUS
*************
4 1-686-493-11 PWB, SWITCH FLEXIBLE
16 1-756-318-11 BATTERY, LITHIUM ION STORAGE
20 1-686-494-11 PWB, POWER RELAY FLEXIBLE
0 58 X-3383-261-1 OPTICAL PICK-UP ASSY (ABX-1ES)
M901 8-835-782-01 MOTOR, DC SSM18D (SPINDLE)
M902 8-835-783-01 MOTOR, DC SSM21B (SLED)
******************************************************
ACCESSORIES
************
0 1-477-536-11 ADAPTOR, AC (JEW,KR)
0 1-477-537-11 ADAPTOR, AC (UK,HK)
0 1-477-538-11 ADAPTOR, AC (AEP)
0 1-477-539-11 ADAPTOR, AC (US,CND)
1-477-585-11 REMOTE CONTROL UNIT (RM-MC33ELU)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (JEW,KR)
1-756-303-11 STAND, CHARGE
1-816-921-11 ADAPTOR, HEADPHONE PC-WM10
3-220-749-01 CASE, CARRYING
3-247-809-01 MANUAL, INSTRUCTION (JAPANESE)(JEW,KR)
3-247-809-11 MANUAL, INSTRUCTION (ENGLISH)
3-247-809-21 MANUAL, INSTRUCTION (FRENCH)
(AEP,JEW,KR)
3-247-809-41 MANUAL, INSTRUCTION (SPANISH)
(AEP,JEW,KR)
3-247-809-51 MANUAL, INSTRUCTION (DUTCH) (AEP)
3-247-809-61 MANUAL, INSTRUCTION (SWEDISH) (AEP)
3-247-809-71 MANUAL, INSTRUCTION (ITALIAN) (AEP)
3-247-809-81 MANUAL, INSTRUCTION (PORTUGUESE)(AEP)
3-247-809-91 MANUAL, INSTRUCTION (FINNISH) (AEP)
3-247-810-11 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (UK,HK,JEW,KR)
3-247-810-21 MANUAL, INSTRUCTION (KOREAN) (JEW,KR)
8-953-218-91 RECEIVER MDR-E838SP
3-252-648-01 CLIP (REMOTE CONTROL)
