Sony MZ-N707 OpenMG Jukebox NOTES on installing & operating - Page 62

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
62
MZ-N707
MAIN
C927 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C928 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN501 1-573-360-21 CONNECTOR, FFC/FPC 20P
CN502 1-573-350-11 CONNECTOR, FFC/FPC 10P
CN701 1-816-036-21 CONNECTOR (SQUARE TYPE) (USB) 5P
(USB CONNECTOR)
CN801 1-573-355-11 CONNECTOR, FFC/FPC 15P
< DIODE >
D101 8-719-056-72 DIODE 02DZ2.4-Z (TPH3)
D201 8-719-056-72 DIODE 02DZ2.4-Z (TPH3)
D301 6-500-116-01 DIODE NNCD6.8H-T1
D601 8-719-081-33 DIODE MA2YD1500LS0
D602 8-719-081-33 DIODE MA2YD1500LS0
D603 8-719-081-33 DIODE MA2YD1500LS0
D604 8-719-081-33 DIODE MA2YD1500LS0
D606 8-719-081-35 DIODE MA2YD1700LS0
D607 8-719-081-33 DIODE MA2YD1500LS0
D608 8-719-081-35 DIODE MA2YD1700LS0
D610 8-719-082-45 DIODE RB715W-TL
D701 8-719-420-51 DIODE MA729-TX
D703 8-719-081-33 DIODE MA2YD1500LS0
D803 8-719-017-58 DIODE MA8068-TX
D804 8-719-420-51 DIODE MA729-TX
D901 8-719-081-33 DIODE MA2YD1500LS0
D902 8-719-081-33 DIODE MA2YD1500LS0
D903 8-719-420-51 DIODE MA729-TX
D904 8-719-404-50 DIODE MA111-TX
< FUSE >
0F801 1-576-439-21 FUSE (SMD) 0.25A 125V
< FERRITE BEAD/RESISTOR >
FB301 1-500-329-21 FERRITE
FB302 1-216-864-11 METAL CHIP 0 5% 1/16W
FB303 1-216-864-11 METAL CHIP 0 5% 1/16W
FB304 1-216-864-11 METAL CHIP 0 5% 1/16W
FB305 1-216-864-11 METAL CHIP 0 5% 1/16W
FB306 1-469-084-21 FERRITE
FB701 1-216-864-11 METAL CHIP 0 5% 1/16W
FB702 1-216-864-11 METAL CHIP 0 5% 1/16W
FB703 1-216-864-11 METAL CHIP 0 5% 1/16W
FB704 1-216-864-11 METAL CHIP 0 5% 1/16W
FB801 1-216-864-11 METAL CHIP 0 5% 1/16W
FB802 1-216-864-11 METAL CHIP 0 5% 1/16W
FB803 1-216-864-11 METAL CHIP 0 5% 1/16W
FB804 1-216-864-11 METAL CHIP 0 5% 1/16W
FB805 1-216-864-11 METAL CHIP 0 5% 1/16W
FB806 1-216-864-11 METAL CHIP 0 5% 1/16W
< IC >
IC301 8-759-694-88 IC AK5354VT-E2
IC302 8-759-598-15 IC TA2131FL (EL)
IC303 8-759-825-56 IC NJM2173AV (TE2)
IC501 6-701-391-01 IC SN761057A
IC551 6-700-680-01 IC SC111258FCR2
IC601 6-701-477-01 IC XPC18A22AFCR2
IC604 6-700-958-01 IC XC61FS1YXXMR
IC702 6-702-333-01 IC XC6367A361MR
@ IC801 8-752-930-27 IC CXD2677-202GA
IC804 8-759-593-47 IC AK6417AM-E2
IC901 8-759-698-61 IC XPC18A32FCR2
IC902 6-701-978-01 IC XC61CN0802NR
< JACK >
J301 1-815-950-11 JACK (LINE IN (OPTICAL))
J302 1-793-288-43 JACK (i)
J303 1-794-084-12 JACK (MIC (PLUG IN POWER))
J601 1-785-383-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 3V)
J602 1-815-912-21 JACK, DC (FOR CHARGING STAND)
< COIL/SHORT >
L301 1-414-398-11 INDUCTOR 10uH
L303 1-414-398-11 INDUCTOR 10uH
L501 1-414-398-11 INDUCTOR 10uH
L502 1-414-398-11 INDUCTOR 10uH
L551 1-216-296-11 SHORT 0
L552 1-216-296-11 SHORT 0
L553 1-216-296-11 SHORT 0
L554 1-216-296-11 SHORT 0
L601 1-428-912-21 CHOKE COIL 10uH
L602 1-414-398-11 INDUCTOR 10uH
L701 1-469-952-21 CHOKE COIL 22uH
L801 1-216-296-11 SHORT 0
L802 1-469-535-21 INDUCTOR 10uH
L901 1-419-953-21 CHOKE COIL 100uH
L902 1-419-949-21 CHOKE COIL 22uH
L904 1-414-398-11 INDUCTOR 10uH
L905 1-469-426-21 INDUCTOR 100uH
L906 1-469-367-21 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q302 8-729-051-23 TRANSISTOR 2SA2018TL
Q501 8-729-922-10 TRANSISTOR 2SA1577-T106-QR
Q601 8-729-046-45 FET SI2302DS-T1
Q602 8-729-046-44 TRANSISTOR ZDT6718TA
Q603 8-729-053-71 FET TS8K1TB
Q604 8-729-046-43 FET HAT2051T-EL
Q605 8-729-046-42 FET HAT2050T-EL
Q608 8-729-426-51 TRANSISTOR XP1210-TXE
Q701 8-729-053-03 FET XP151A12A2MR
Q703 8-729-037-86 TRANSISTOR 2SB1462J-R (TX).SO
Q704 8-729-041-51 TRANSISTOR FMMT617TA
Q705 8-729-047-48 TRANSISTOR UMD12N-TR
Q706 8-729-037-63 TRANSISTOR UN9115J-(TX).SO
Q801 8-729-429-44 TRANSISTOR XP1501-TXE
Q901 8-729-037-92 TRANSISTOR 2SD2216J-R (TX).SO
Q902 8-729-037-92 TRANSISTOR 2SD2216J-R (TX).SO
Q903 8-729-037-92 TRANSISTOR 2SD2216J-R (TX).SO
Q904 8-729-034-59 TRANSISTOR 2SA1745-6.7-TL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
@Replacement of CXD2677-202GA (IC801)
used in this set requires a special tool.
