Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
MZ-N707
< RESISTOR >
R101 1-218-969-11 RES-CHIP 22K 5% 1/16W
R102 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R103 1-218-973-11 RES-CHIP 47K 5% 1/16W
R104 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(FR)
R104 1-218-965-11 RES-CHIP 10K 5% 1/16W
(EXCEPT US, FR)
R104 1-218-969-11 RES-CHIP 22K 5% 1/16W
(US)
R105 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R106 1-208-635-11 RES-CHIP 10 5% 1/16W
R107 1-218-965-11 RES-CHIP 10K 5% 1/16W
R111 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R112 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R118 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R201 1-218-969-11 RES-CHIP 22K 5% 1/16W
R202 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R203 1-218-973-11 RES-CHIP 47K 5% 1/16W
R204 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(FR)
R204 1-218-965-11 RES-CHIP 10K 5% 1/16W
(EXCEPT US, FR)
R204 1-218-969-11 RES-CHIP 22K 5% 1/16W
(US)
R205 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R206 1-208-635-11 RES-CHIP 10 5% 1/16W
R207 1-218-965-11 RES-CHIP 10K 5% 1/16W
R211 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R212 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R218 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R302 1-218-953-11 RES-CHIP 1K 5% 1/16W
R303 1-218-937-11 RES-CHIP 47 5% 1/16W
R304 1-218-953-11 RES-CHIP 1K 5% 1/16W
R305 1-218-953-11 RES-CHIP 1K 5% 1/16W
R306 1-218-969-11 RES-CHIP 22K 5% 1/16W
R307 1-218-941-11 RES-CHIP 100 5% 1/16W
R308 1-218-990-11 SHORT 0
R309 1-218-981-11 RES-CHIP 220K 5% 1/16W
R310 1-218-990-11 SHORT 0
R311 1-218-989-11 RES-CHIP 1M 5% 1/16W
R315 1-218-965-11 RES-CHIP 10K 5% 1/16W
R316 1-218-977-11 RES-CHIP 100K 5% 1/16W
R317 1-218-941-11 RES-CHIP 100 5% 1/16W
R318 1-218-953-11 RES-CHIP 1K 5% 1/16W
R319 1-218-953-11 RES-CHIP 1K 5% 1/16W
R320 1-218-965-11 RES-CHIP 10K 5% 1/16W
R501 1-218-973-11 RES-CHIP 47K 5% 1/16W
R502 1-218-981-11 RES-CHIP 220K 5% 1/16W
R503 1-218-985-11 RES-CHIP 470K 5% 1/16W
R505 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R507 1-218-953-11 RES-CHIP 1K 5% 1/16W
R517 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R519 1-218-977-11 RES-CHIP 100K 5% 1/16W
R521 1-218-446-11 METAL CHIP 1 5% 1/10W
R522 1-218-446-11 METAL CHIP 1 5% 1/10W
R551 1-218-965-11 RES-CHIP 10K 5% 1/16W
R552 1-218-965-11 RES-CHIP 10K 5% 1/16W
R553 1-218-965-11 RES-CHIP 10K 5% 1/16W
R560 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R561 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R562 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R601 1-218-989-11 RES-CHIP 1M 5% 1/16W
R602 1-218-981-11 RES-CHIP 220K 5% 1/16W
R603 1-218-977-11 RES-CHIP 100K 5% 1/16W
R604 1-218-446-11 METAL CHIP 1 5% 1/10W
R605 1-218-446-11 METAL CHIP 1 5% 1/10W
R606 1-218-949-11 RES-CHIP 470 5% 1/16W
R607 1-218-945-11 RES-CHIP 220 5% 1/16W
R608 1-218-981-11 RES-CHIP 220K 5% 1/16W
R609 1-219-724-11 METAL CHIP 1 1% 1/4W
R610 1-218-969-11 RES-CHIP 22K 5% 1/16W
R612 1-218-985-11 RES-CHIP 470K 5% 1/16W
R613 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R614 1-218-965-11 RES-CHIP 10K 5% 1/16W
R615 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R616 1-218-953-11 RES-CHIP 1K 5% 1/16W
R620 1-218-965-11 RES-CHIP 10K 5% 1/16W
R621 1-218-965-11 RES-CHIP 10K 5% 1/16W
R622 1-218-977-11 RES-CHIP 100K 5% 1/16W
R623 1-218-977-11 RES-CHIP 100K 5% 1/16W
R624 1-216-797-11 METAL CHIP 10 5% 1/16W
R625 1-218-977-11 RES-CHIP 100K 5% 1/16W
R626 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R701 1-218-953-11 RES-CHIP 1K 5% 1/16W
R702 1-218-985-11 RES-CHIP 470K 5% 1/16W
R703 1-218-985-11 RES-CHIP 470K 5% 1/16W
R704 1-218-990-11 SHORT 0
R705 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R706 1-218-977-11 RES-CHIP 100K 5% 1/16W
R707 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R708 1-218-985-11 RES-CHIP 470K 5% 1/16W
R709 1-218-941-11 RES-CHIP 100 5% 1/16W
R710 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R711 1-216-864-11 METAL CHIP 0 5% 1/16W
R712 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R714 1-218-990-11 SHORT 0
R715 1-218-973-11 RES-CHIP 47K 5% 1/16W
R801 1-218-981-11 RES-CHIP 220K 5% 1/16W
R802 1-208-903-11 METAL CHIP 4.7K 0.5% 1/16W
R803 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R804 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R805 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R806 1-218-949-11 RES-CHIP 470 5% 1/16W
R807 1-208-635-11 RES-CHIP 10 5% 1/16W
R808 1-218-965-11 RES-CHIP 10K 5% 1/16W
R809 1-218-977-11 RES-CHIP 100K 5% 1/16W
R810 1-218-977-11 RES-CHIP 100K 5% 1/16W
R814 1-208-635-11 RES-CHIP 10 5% 1/16W
R815 1-218-990-11 SHORT 0
R816 1-218-990-11 SHORT 0
R817 1-218-977-11 RES-CHIP 100K 5% 1/16W
R821 1-218-981-11 RES-CHIP 220K 5% 1/16W
R822 1-218-953-11 RES-CHIP 1K 5% 1/16W
R823 1-218-945-11 RES-CHIP 220 5% 1/16W
R824 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
MAIN
