Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
64
MZ-N707
R825 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R826 1-218-990-11 SHORT 0
R827 1-216-864-11 METAL CHIP 0 5% 1/16W
R828 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R829 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R830 1-218-989-11 RES-CHIP 1M 5% 1/16W
R831 1-218-990-11 SHORT 0
R832 1-218-985-11 RES-CHIP 470K 5% 1/16W
R833 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R834 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R835 1-208-951-11 METAL CHIP 470K 0.5% 1/16W
R836 1-218-990-11 SHORT 0
R838 1-218-949-11 RES-CHIP 470 5% 1/16W
R839 1-218-989-11 RES-CHIP 1M 5% 1/16W
R840 1-216-809-11 METAL CHIP 100 5% 1/16W
R841 1-218-990-11 SHORT 0
R843 1-216-864-11 METAL CHIP 0 5% 1/16W
R844 1-218-990-11 SHORT 0
R845 1-208-643-11 RES-CHIP 22 5% 1/16W
R846 1-208-643-11 RES-CHIP 22 5% 1/16W
R847 1-218-990-11 SHORT 0
R849 1-218-990-11 SHORT 0
R850 1-218-990-11 SHORT 0
R851 1-218-990-11 SHORT 0
R852 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R853 1-218-990-11 SHORT 0
R855 1-218-990-11 SHORT 0
R857 1-218-953-11 RES-CHIP 1K 5% 1/16W
R858 1-218-989-11 RES-CHIP 1M 5% 1/16W
R859 1-218-953-11 RES-CHIP 1K 5% 1/16W
R860 1-218-953-11 RES-CHIP 1K 5% 1/16W
R861 1-218-953-11 RES-CHIP 1K 5% 1/16W
R863 1-218-977-11 RES-CHIP 100K 5% 1/16W
R864 1-218-977-11 RES-CHIP 100K 5% 1/16W
R902 1-218-985-11 RES-CHIP 470K 5% 1/16W
R903 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R905 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R906 1-218-990-11 SHORT 0
R907 1-218-989-11 RES-CHIP 1M 5% 1/16W
R908 1-218-977-11 RES-CHIP 100K 5% 1/16W
R909 1-218-965-11 RES-CHIP 10K 5% 1/16W
R910 1-218-965-11 RES-CHIP 10K 5% 1/16W
R911 1-218-949-11 RES-CHIP 470 5% 1/16W
R914 1-218-941-11 RES-CHIP 100 5% 1/16W
R915 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R916 1-218-981-11 RES-CHIP 220K 5% 1/16W
R917 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R918 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R919 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R920 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R921 1-218-985-11 RES-CHIP 470K 5% 1/16W
R922 1-218-969-11 RES-CHIP 22K 5% 1/16W
R923 1-218-981-11 RES-CHIP 220K 5% 1/16W
R924 1-218-981-11 RES-CHIP 220K 5% 1/16W
R925 1-218-981-11 RES-CHIP 220K 5% 1/16W
R927 1-218-989-11 RES-CHIP 1M 5% 1/16W
R928 1-218-977-11 RES-CHIP 100K 5% 1/16W
R936 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R941 1-218-969-11 RES-CHIP 22K 5% 1/16W
R946 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R947 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R948 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
< SWITCH >
S803 1-771-867-11 SWITCH, PUSH (1 KEY) (PROTECT DETECT)
S805 1-762-946-12 SWITCH, PUSH (1 KEY) (OPEN)
S806 1-762-805-21 SWITCH, PUSH (1 KEY)
(OPEN/CLOSE DETECT)
< EMI FILTER >
T601 1-416-405-21 EMI FILTER
< THERMISTOR >
TH601 1-804-616-21 THERMISTOR, POSITIVE
< VIBRATOR >
X801 1-795-024-11 VIBRATOR, CRYSTAL (45.1584MHz)
X802 1-795-443-21 VIBRATOR, CRYSTAL (48MHz)
**************************************************************
MISCELLANEOUS
**************
4 1-804-543-11 LCD MODULE
0 309 X-3381-589-1 SERVICE ASSY, OP (LCX-5R)
M601 8-835-744-01 MOTOR, DC SSM18B (SPINDLE)
(WITH TURN TABLE)
M602 1-763-727-11 MOTOR, DC (SLED) (WITH GEAR)
M603 1-763-400-21 MOTOR, DC (OVER WRITE HEAD UP/DOWN)
************************************************************
ACCESSORIES
************
1-251-824-12 CONNECTING PACK, CAR (CPA-7) (US, CND)
1-476-211-22 REMOTE CONTROL UNIT (RM-MC10L/B)
(AEP, UK, FR)
1-476-303-11 REMOTE CONTROL UNIT (RM-MZ4R)
(US, CND)
0 1-476-857-11 ADAPTOR, AC (AC-ES305) (AEP, FR)
0 1-476-858-11 ADAPTOR, AC (AC-ES305) (UK)
0 1-476-859-11 ADAPTOR, AC (AC-ES305) (US, CND)
1-756-145-21 BATTERY, NICKEL CADMIUM (AEP, UK, FR)
1-756-145-31 BATTERY, NICKEL CADMIUM (US, CND)
0 1-756-229-11 STAND, CHARGE
1-816-206-11 CONNECTOR, LIGHT
1-823-519-11 CORD, CONNECTION (USB CABLE)
3-223-571-01 CASE, BATTERY CARRYING
3-228-300-11 CASE, BELT CLIP CARRYING (EXCEPT US)
3-234-038-11 MANUAL, INSTRUCTION (ENGLISH) (AEP, UK)
3-234-038-21 MANUAL, INSTRUCTION (FRENCH) (AEP, FR)
3-234-038-31 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN) (AEP)
3-234-038-41 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (AEP)
3-234-038-51 MANUAL, INSTRUCTION (SWEDISH, FINNISH)
(AEP)
MAIN
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
