Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
65
MZ-S1
MAIN
R601 1-218-989-11 RES-CHIP 1M 5% 1/16W
R602 1-218-981-11 RES-CHIP 220K 5% 1/16W
R603 1-218-977-11 RES-CHIP 100K 5% 1/16W
R607 1-218-945-11 RES-CHIP 220 5% 1/16W
R608 1-218-981-11 RES-CHIP 220K 5% 1/16W
R609 1-219-724-11 METAL CHIP 1 1% 1/4W
R610 1-218-969-11 RES-CHIP 22K 5% 1/16W
R612 1-218-985-11 RES-CHIP 470K 5% 1/16W
R613 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R614 1-218-965-11 RES-CHIP 10K 5% 1/16W
R616 1-218-977-11 RES-CHIP 100K 5% 1/16W
R620 1-218-965-11 RES-CHIP 10K 5% 1/16W
R621 1-218-965-11 RES-CHIP 10K 5% 1/16W
R622 1-218-977-11 RES-CHIP 100K 5% 1/16W
R623 1-218-977-11 RES-CHIP 100K 5% 1/16W
R624 1-216-797-11 METAL CHIP 10 5% 1/16W
R701 1-218-953-11 RES-CHIP 1K 5% 1/16W
R702 1-218-985-11 RES-CHIP 470K 5% 1/16W
R703 1-218-985-11 RES-CHIP 470K 5% 1/16W
R704 1-218-990-11 SHORT 0
R705 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R706 1-218-977-11 RES-CHIP 100K 5% 1/16W
R707 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R708 1-218-985-11 RES-CHIP 470K 5% 1/16W
R709 1-218-941-11 RES-CHIP 100 5% 1/16W
R710 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R711 1-216-864-11 METAL CHIP 0 5% 1/16W
R712 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R714 1-218-990-11 SHORT 0
R715 1-218-973-11 RES-CHIP 47K 5% 1/16W
R801 1-218-981-11 RES-CHIP 220K 5% 1/16W
R802 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R803 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R804 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R805 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R806 1-218-949-11 RES-CHIP 470 5% 1/16W
R807 1-208-635-11 RES-CHIP 10 5% 1/16W
R808 1-218-965-11 RES-CHIP 10K 5% 1/16W
R809 1-218-977-11 RES-CHIP 100K 5% 1/16W
R810 1-218-977-11 RES-CHIP 100K 5% 1/16W
R812 1-218-990-11 SHORT 0
R814 1-208-635-11 RES-CHIP 10 5% 1/16W
R815 1-218-990-11 SHORT 0
R816 1-218-990-11 SHORT 0
R817 1-218-977-11 RES-CHIP 100K 5% 1/16W
R821 1-218-981-11 RES-CHIP 220K 5% 1/16W
R822 1-218-953-11 RES-CHIP 1K 5% 1/16W
R823 1-218-945-11 RES-CHIP 220 5% 1/16W
R824 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R825 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R826 1-218-990-11 SHORT 0
R827 1-216-864-11 METAL CHIP 0 5% 1/16W
R828 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R829 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R830 1-218-989-11 RES-CHIP 1M 5% 1/16W
R831 1-218-990-11 SHORT 0
R832 1-218-985-11 RES-CHIP 470K 5% 1/16W
R833 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R834 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R835 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R838 1-218-949-11 RES-CHIP 470 5% 1/16W
R839 1-218-989-11 RES-CHIP 1M 5% 1/16W
R840 1-216-809-11 METAL CHIP 100 5% 1/16W
R841 1-218-990-11 SHORT 0
R843 1-216-864-11 METAL CHIP 0 5% 1/16W
R844 1-218-990-11 SHORT 0
R845 1-208-643-11 RES-CHIP 22 5% 1/16W
R846 1-208-643-11 RES-CHIP 22 5% 1/16W
R847 1-218-990-11 SHORT 0
R849 1-218-990-11 SHORT 0
R850 1-218-990-11 SHORT 0
R851 1-218-990-11 SHORT 0
R852 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R853 1-218-990-11 SHORT 0
R855 1-218-990-11 SHORT 0
R857 1-218-953-11 RES-CHIP 1K 5% 1/16W
R858 1-218-989-11 RES-CHIP 1M 5% 1/16W
R859 1-218-953-11 RES-CHIP 1K 5% 1/16W
R860 1-218-953-11 RES-CHIP 1K 5% 1/16W
R861 1-218-953-11 RES-CHIP 1K 5% 1/16W
R863 1-218-977-11 RES-CHIP 100K 5% 1/16W
R864 1-218-977-11 RES-CHIP 100K 5% 1/16W
R902 1-218-985-11 RES-CHIP 470K 5% 1/16W
R903 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R905 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R906 1-218-990-11 SHORT 0
R907 1-218-989-11 RES-CHIP 1M 5% 1/16W
R908 1-218-977-11 RES-CHIP 100K 5% 1/16W
R909 1-218-965-11 RES-CHIP 10K 5% 1/16W
R910 1-218-965-11 RES-CHIP 10K 5% 1/16W
R911 1-218-949-11 RES-CHIP 470 5% 1/16W
R914 1-218-941-11 RES-CHIP 100 5% 1/16W
R915 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R916 1-218-981-11 RES-CHIP 220K 5% 1/16W
R917 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R918 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R919 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R920 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R921 1-218-985-11 RES-CHIP 470K 5% 1/16W
R922 1-218-969-11 RES-CHIP 22K 5% 1/16W
R923 1-218-981-11 RES-CHIP 220K 5% 1/16W
R924 1-218-981-11 RES-CHIP 220K 5% 1/16W
R925 1-218-981-11 RES-CHIP 220K 5% 1/16W
R927 1-218-989-11 RES-CHIP 1M 5% 1/16W
R928 1-218-977-11 RES-CHIP 100K 5% 1/16W
R936 1-208-919-11 METAL CHIP 22K 0.5% 1/16W
R941 1-218-969-11 RES-CHIP 22K 5% 1/16W
R946 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R947 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R948 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
< SWITCH >
S801 1-762-078-11 SWITCH, SLIDE (HOLD)
S803 1-771-867-11 SWITCH, PUSH (1 KEY) (PROTECT DETECT)
S805 1-762-947-12 SWITCH, PUSH (1 KEY) (HALF LOCK)
