Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
66
MZ-S1
S806 1-762-805-21 SWITCH, PUSH (1 KEY)
(OPEN/CLOSE DETECT)
< LINE FILTER >
T601 1-416-405-21 LINE FILTER
< THERMISTOR >
TH601 1-804-616-21 THERMISTOR, POSITIVE
< VIBRATOR >
X801 1-795-024-11 VIBRATOR, CRYSTAL (45.1584MHz)
X802 1-795-443-21 VIBRATOR, CRYSTAL (48MHz)
**************************************************************
MISCELLANEOUS
**************
8 1-804-544-11 LCD MODULE
165 1-476-938-11 SWITCH UNIT
0309 X-3381-589-1 SERVICE ASSY, OP (LCX-5R)
M601 8-835-744-01 MOTOR, DC SSM18B (SPINDLE)
(WITH TURN TABLE)
M602 1-763-727-11 MOTOR, DC (SLED) (WITH GEAR)
M603 1-763-400-21 MOTOR, DC (OVER WRITE HEAD UP/DOWN)
************************************************************
ACCESSORIES
************
0 1-476-857-11 ADAPTOR, AC (AC-ES305) (AEP, FR)
0 1-476-858-11 ADAPTOR, AC (AC-ES305) (UK)
0 1-476-859-11 ADAPTOR, AC (AC-ES305) (US, CND)
1-816-206-11 CONNECTOR, LIGHT (OPTICAL CABLE)
(AEP, UK, FR)
1-823-519-11 CORD, CONNECTION (USB CABLE)
3-237-042-11 SOFT (CD-ROM), APPLICATION (US, CND)
3-237-042-21 SOFT (CD-ROM), APPLICATION (AEP, UK, FR)
3-238-523-01 STRAP, HAND
3-239-099-12 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH)
3-239-099-21 MANUAL, INSTRUCTION (SWEDISH,
PORTUGUESE, FINNISH) (AEP)
3-239-099-31 MANUAL, INSTRUCTION (GERMAN, DUTCH,
ITALIAN) (AEP)
3-239-304-11 MANUAL, INSTRUCTION (How to Install)
(Simple Burner) (ENGLISH) (US, CND)
3-239-304-21 MANUAL, INSTRUCTION (How to Install)
(Simple Burner) (FRENCH) (CND)
3-239-305-11 CARD (OPERATING INSTRUCTION)
(Simple Burner) (ENGLISH) (US, CND)
3-239-305-21 CARD (OPERATING INSTRUCTION)
(Simple Burner) (FRENCH) (CND)
3-239-307-11 MANUAL, INSTRUCTION (OpenMG Jukebox)
(ENGLISH) (US, CND, AEP, UK)
3-239-307-21 MANUAL, INSTRUCTION (OpenMG Jukebox)
(FRENCH) (CND, AEP, FR)
3-239-307-31 MANUAL, INSTRUCTION (OpenMG Jukebox)
(GERMAN) (AEP)
3-239-307-41 MANUAL, INSTRUCTION (OpenMG Jukebox)
(SPANISH) (AEP)
3-239-307-51 MANUAL, INSTRUCTION (OpenMG Jukebox)
(DUTCH) (AEP)
MAIN
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
3-239-307-61 MANUAL, INSTRUCTION (OpenMG Jukebox)
(SWEDISH) (AEP)
3-239-307-71 MANUAL, INSTRUCTION (OpenMG Jukebox)
(ITALIAN) (AEP)
3-239-307-91 MANUAL, INSTRUCTION (OpenMG Jukebox)
(FINNISH) (AEP)
8-953-284-95 RECEIVER, EAR MDR-W014LP/WK (US, CND)
8-954-008-94 RECEIVER MDR-E808LP/WC (AEP, UK, FR)
