PCM-D50
60
Pin No.Pin NameI/O Description
AE14AVDD_LPLL — Power supply (VDD_PLL)
AE15AVDD_HPLL — Power supply (VDD_PLL)
AE16 GND — Ground
AE17DD1VFBKIVDD_L1 power supply voltage feedback input
AE18VDD_DSP — Power supply (VDD_L1)
AE19 IO_A — Power supply (VDD_IOA)
AE20 VGP12IN — Power supply (+3.3V)
AE21 VGP3IN — Power supply (+3.3V)
AE22 VGP4 OVDD_GP4 power supply output
AE23 VGP5 OVDD_GP5 power supply output (Not used in this set) (Open)
AE24 VGP45IN — Power supply (+3.3V)
AE25, AE26,
AF1 to AF3
NC — Not used (Open)
AF4 DD2VFB2IVDD_SDR Power supply voltage feedback input
AF5, AF6DD2INB1, DD2INB2 — Power supply (+3.3V)
AF7 to AF9
DD2LX3, DD2LX1,
DD2LX2
OVDD_SDR Power supply switching drive output
AF10, AF11DD2GNDB1, DD2GNDB2 — Ground
AF12, AF13DD1GNDB1, DD1GNDB2 — Ground
AF14, AF15 DD1LX1,DD1LX2OPower supply switching drive output
AF16, AF17 DD1INB1,DD1INB2 — Power supply (+3.3V)
AF18DD1VFBK2IVDD_L1 power supply voltage feedback input
AF19DD1GNDA — Ground
AF20VGP1OVDD_GP1 power supply output
AF21COM — Not used (Open)
AF22VGP2OVDD_GP2 power supply output
AF23VGP3OVDD_GP3 power supply output
AF24 to
AF26
NC — Not used (Open)
