Sony PCM-D50 - Page 59

PCM-D50
59
Pin No.Pin NameI/O Description
AC9 IO_C — Power supply (VDD_GP1)
AC10CAM_YUV6OPWM signal output to the DC/DC converter
AC11CAM_YUV2OPower supply control signal output
AC12 CAM_VSOLINE OUT (OPT) transmitter power control signal output
AC13 ISENSE — Not used (Open)
AC14AVDD_LPLL — Power supply (VDD_PLL)
AC15AVDD_HPLL — Power supply (VDD_PLL)
AC16MS_DATA1I/OMS data input/output
AC17 MS_BSI/OMS_BS signal input/output
AC18MS_SCK0I/OMS clock signal input/output
AC19 IIC_SCLI/OVBUS/SELF power control signal output
AC20 PM1_SOOSerial data signal output (Not used in this set) (Open)
AC21PM0_CLKOSerial clock signal output to the D/A converter
AC22 PM0_SOOSerial audio date output to the D/A converter
AC23 PWM0 OLCD backlight control signal output
AC24 VL0IN — Power supply (VDD_IOA)
AC25 IO_C — Power supply (VDD_GP1)
AC26 OSCOUTOSub system clock output (32.768kHz)
AD1 NC — Not used (Open)
AD2 GPIO3 IREC (S2201) key signal input
AD3 GPIO2 ILINE OUT (OPT) connection detection signal input
AD4 GPIO1 IHOLD switch signal input
AD5 GPIO0 IKey wake up signal input
AD6 ADINT — Not used (Open)
AD7SPI0_CSZ2OChip select signal output to the D/A converter
AD8 VDD_L1 — Power supply (VDD_L1)
AD9 IO_C — Power supply (VDD_GP1)
AD10CAM_YUV5OMIC power supply control signal output
AD11CAM_YUV1OADC power supply control signal output
AD12 CAM_HSO11.2896MHz clock generator control signal output
AD13 TEST — Not used (Open)
AD14AVDD_LPLL — Power supply (VDD_PLL)
AD15AVDD_HPLL — Power supply (VDD_PLL)
AD16 OSENSE — Not used (Open)
AD17 BKBAT ILithium battery voltage detection input
AD18 IO_A — Power supply (VDD_IOA)
AD19 IIC_SDAOPWM signal output to the DC/DC converter
AD20 PM1_SI ISerial audio date input from the D/A converter
AD21 GND2 — Ground
AD22 PM0_SI ISerial audio date input from the D/A converter
AD23 PWM1 OSircs control signal output
AD24STM_DATAISTM data input
AD25 GND3 — Ground
AD26,
AE1, AE2
NC — Not used (Open)
AE3 DD2VFBKIVDD_SDR power supply voltage feedback input
AE4DD2VFBSWOVDD_IOA power supply output
AE5 DD2GNDA — Ground
AE6 DD2INA — Power supply (+3.3V)
AE7 VDD_L0 — Power supply (VDD_L0)
AE8 VDD_L1 — Power supply (VDD_L1)
AE9 IO_C — Power supply (VDD_GP1)
AE10CAM_YUV4OMic bias control signal output
AE11CAM_YUV0OHeadphone amp power control signal output
AE12 DD1INA — Power supply (+3.3V)
AE13 IO_B — Power supply (VDD_GP1)
