Specifications
35
: Adjustable/can be set
– : Not adjustable/cannot be set
1) Compatible with 1/1.001 frame rates.
2) 1080/25PsF, 30PsF are displayed as 1080/25PsF, 30PsF on the screen
if the payload ID is added to the video signal, or displayed as 1080/50I,
60I if the ID is not added.
3) 10-bit 4:4:4 YCbCr and 4:4:4 RGB signals are supported.
4) 10-bit 4:2:2 YCbCr signal is supported.
Applicable signals from PC
This unit is compatible with the following PC signals.
The sides of the displayed picture may be hidden
depending on the input signal.
System
Com-
posite
SD/
HD
Dual
Link
3G HDMI
575/50i (PAL) ––
480/60i (NTSC)
1)
––
576/50p – – – –
480/60p
1)
––––
640 × 480/60p
1)
––––
1080/24PsF
1)
–
3)
3)
–
1080/25PsF
2)
–
3)
3)
–
1080/30PsF
1)
2)
–
3)
3)
–
1080/24p
1)
–
3)
3)
1080/25p –
3)
3)
1080/30p
1)
–
3)
3)
1080/50i –
3)
3)
1080/60i
1)
–
3)
3)
1080/50p – –
4)
4)
1080/60p
1)
––
4)
4)
720/24p
1)
– –––
720/25p – –––
720/30p
1)
– –––
720/50p – –
3)
720/60p
1)
– –
3)
2048/24PsF
1)
–
3)
3)
–
2048/25PsF
2)
–
3)
3)
–
2048/30PsF
1)
2)
–
3)
3)
–
2048/24p
1)
–
3)
3)
–
2048/25p –
3)
3)
–
2048/30p
1)
–
3)
3)
–
2048/48p
1)
––
4)
4)
–
2048/50p – –
4)
4)
–
2048/60p
1)
––
4)
4)
–
System HDMI/DVI
Resolution
Dot clock
(MHz)
fH (kHz) fV (Hz)
640 × 480 25.175 31.5
60
1280 × 768 68.250 47.4
1280 × 1024 108.000 64.0
1360 × 768 85.500 47.7
1440 × 900 88.750 55.5
1680 × 1050 119.000 64.7
