Sony RCD-W10 User Manual

28
Additional Information
Using the Setup Menu
You can make various settings on this unit by
using the Setup Menu.
When using the remote, set SELECT to CDR.
1 Press MENU/NO.
2 Turn AMS (or press ./> on the
remote) to select the setup item, and
press AMS (or YES).
3 Turn AMS (or press ./> on the
remote) to set the item, and press AMS
(or YES).
4 Press MENU/NO.
To initialize an item’s parameter
Press CLEAR after Step 2.
Notes
• The menus you can use while the unit is stopped,
playing, or recording differ.
• The setting is stored in memory even if you turn off
the unit or disconnect the power.
./>
SELECT
Setup item
Track Mark
LSync Lvl
Silent Pause
Direct
Text Save
Post Gap
DECK A Lvl
Optical Lvl
Function (reference page)
Sets the Track Marking Function (page 22).
Changes the trigger level for Track Marking Function (page
22).
Sets the Silent Pause Function (page 17).
Sets the Direct Recording Function (page 23).
Records the CD text automatically at Make-Disc Synchro-
Recording (page 18).
Sets the function to add Post Gap. (page 17).
Adjusts the input level from the CD player section (DECK A)
(page 21).
Adjusts the input level from the DIGITAL OPTICAL IN jack
(page 21).
Parameters (Initial setting)
LSync/Off (LSync)
–72 dB to –20 dB in 2 dB
increments (–50 dB)
On/Off (On)
On/Off (Off)
On/Off (On)
On/Off (Off)
– ∞ dB to 18.0 dB (0.0 dB)
– ∞ dB to 18.0 dB (0.0 dB)
Menu items
MENU/NO
MENU/NO
AMS
CLEAR
CLEAR
YES
YES

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
