Sony RCD-W10 User Manual

32
Specifications
DECK A (the CD player section)
System Compact disc digital audio
system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Frequency response 20 Hz – 20,000 Hz (±0.5
dB)
DECK B (the CD-R and CD-RW
recording section)
System Compact disc digital audio
system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Playable discs CD, CD-R, CD-RW
Recordable discs CD-R, CD-RW (for music
use)
Frequency response 20 Hz - 20,000 Hz (±0.5
dB)
Inputs
ANALOG IN
(Phono jacks) Impedance: 47 kilohms
Rated input: 500 mVrms
Minimum input
250 mVrms
DIGITAL OPTICAL IN
(Square optical connector jack)
Optical wavelength:
660 nm
Outputs
ANALOG OUT
(Phono jacks) Impedance: 47 kilohms
Rated output: 2 Vrms
Load impedance: over
10 kilohms
DIGITAL OPTICAL OUT
(Square optical connector jack)
Wavelength: 660 nm
Output level: –18 dBm
PHONES
(Phono jack) Load impedance: 32 ohms
Output level: 12mW
General
Power requirements
North American model: 120 V AC, 60 Hz
Mexican model: 120 V AC, 60 Hz
Other models: 110-120/220-240V AC,
50/60 Hz
Power consumption 25 W
Dimensions (approx.) (w/h/d) incl. projecting parts
and control 430 × 108 × 399 mm
( 17 × 4
3
/
8
× 15
3
/
4
inch)
Mass (approx.) RCD-W50C: 6.8 kg
(15 lbs)
RCD-W10: 6.0 kg
(13 lbs 4 oz)
Supplied accessories See page 6.
Design and specifications are subject to change
without notice.
Sony Corporation Printed in Malaysia

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
