Sony RMT-D175A - Power Board (SRV2019 UC) Printed Wiring Board

DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
POWER BOARD (SRV2019UC) PRINTED WIRING BOARD
(DVP-NS72HP: US/NS77H: US/NS77HP: MX/NS78H: CND)
POWER BOARD (SRV2019UC) (SIDE A)
POWER BOARD (SRV2019UC) (SIDE B)
• : Uses unleaded solder.
4 -304-29
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
For printed wiring board
POWER BOARD
(SRV2019UC)
SIDE A
IC101 B-4
Q211 A-6
D106 C-4
D107 A-3
D108 A-4
D211 A-5
D212 C-5
D311 B-5
D312 B-6
D313 B-5
D315 A-6
D317 A-6
D411 B-5
D511 C-5
SIDE B
IC611 A-3
Q311 A-1
Q611 B-2
Q712 A-1
D101 B-6
B
A
1
2
765
43
B
A
1
2
765
43
POWER BAORD
(SRV2019UC)
IF-154 Board
(INTERFACE)
SW-512 Board
(SWITCH BOARD)
MV-55 Board
(SYSTEM, DRIVE, VIDEO, AUDIO, POWER)
(DVP-NS72HP/NS77H/NS77HP/
NS78H: CND,SP,KR,TH/NS78HP: E,BR)
MV-56 Board
(SYSTEM, DRIVE, VIDEO, AUDIO, POWER)
DVP-NS78H: AEP,UK,RUS)
Power Board
SRV2019UC (DVP-NS72HP/NS77H: US/NS77HP: MX/NS78H: CND)
SRV2020WW (DVP-NS78H: EXCEPT CND/NS78HP)
