Sony RMT-D175A - Main Section Parts List (Specific Models)

8-2
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
Ref. No. Part No. Description Remark
DVP-NS72HP/NS77H/NS77HP/NS78H: CND, KR, SP, BR,TH/NS78HP: E,BR
Ref. No. Part No. Description Remark
Note :
The components identified by mark
or
dotted line with mark are critical for
safety.
Replace only with part number specified.
Note :
The components identified by mark
contain confidential information. Strictly
follow the instructions whenever the
components are repaired and/or
replaced.
1 3-077-331-11 +BV3 (3-CR)
2 3-077-331-21 +BV3 (3-CR)
3 1-830-279-21 FLEXIBLE FLAT CABLE (FMO-008)
* 4 1-834-190-11 CABLE, FLEXIBLE FLAT (FIM-018)
5 3-071-119-91 COVER, BATTERY
6 2-319-080-31 COVER, TRAY (BLACK)
(DVP-NS72HP/NS77H:US/
NS77HP:MX/NS78H:CND/NS78HP:E)
6 2-319-080-21 COVER, TRAY (SILVER)
(DVP-NS77H:US/NS78H:SP,KR,TH)
6 2-319-080-41 COVER, TRAY (NS78H:BR/NS78HP:BR) (BLACK)
7 X-2176-379-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS72HP)
7 X-2176-377-1 PANEL ASSY, FRONT (SILVER)
(DVP-NS77H:US)
7 X-2176-378-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS77H:US)
7 X-2187-008-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS77HP:MX)
7 X-2178-182-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS78H:CND)
7 X-2178-183-1 PANEL ASSY, FRONT (SILVER)
(DVP-NS78H:SP,KR,TH)
7 X-2187-009-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS78HP:E)
8 1-474-063-11 POWER SUPPLY BLOCK (DVP-NS72HP/
NS77H:US/NS77HP:MX/NS78H:CND)
8 1-474-062-11 POWER SUPPLY BLOCK
(DVP-NS78H:SP,KR,TH
9 1-828-451-11 POWER-SUPPLY CORD (DVP-NS72HP/
NS77H:US/NS77HP:MX/NS78H:CND)
9 1-828-450-11 POWER-SUPPLY CORD
(DVP-NS78H:SP/NS78HP:E,BR)
9 1-828-871-11 POWER-SUPPLY CORD (DVP-NS78H:KR)
10 1-479-179-11 REMOTE COMMANDER (RMT-D175A)
(NS72HP/NS77H:US/NS77HP:MX/
NS78H:CND,KR,BR/NS78HP:E,BR)
10 1-479-179-21 REMOTE COMMANDER (RMT-D175P)
(DVP-NS78H:SP,TH)
11 3-070-883-41 SCREW, TAPPING (SILVER)
11 3-070-883-71 SCREW, TAPPING (BLACK)
12 A-1224-253-A SERVICE ASSY, CASE UPPER (BLACK)
12 A-1224-171-A SERVICE ASSY, CASE UPPER (SILVER)
13 A-1268-748-A SERVICE ASSY, MV (NS77H)
13 A-1269-126-A SERVICE ASSY, MV (NS77HP:MX)
13 A-1443-600-A SERVICE ASSY, MV (NS72HP)
13 A-1269-132-A SERVICE ASSY, MV (NS78HP:E)
13 A-1269-137-A SERVICE ASSY, MV (NS78H:BR/NS78HP:BR)
13 A-1276-114-A SERVICE ASSY, MV (NS78H:SP,KR,TH)
* 14 1-833-760-11 CABLE, FLEXIBLE FLAT (FSW-003)
* 15 1-834-191-11 CABLE, FLEXIBLE FLAT (FMS-014)
17 3-087-053-01 +BVTP2.6 (3CR)
7 A-1227-597-A PANEL ASSY, FRONT (BLACK)
(DVP-NS78H:BR)
,BR /NS78HP:E
,BR)
7 A-1367-714-A PANEL ASSY, FRONT (NS78HP:BR)
13 A-1269-115-A SERVICE ASSY, MV (NS78H:CND)
