8-4
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
Ref. No. Part No. Description Remark
DVP-NS78H: AEP,UK,RUS
Ref. No. Part No. Description Remark
Note :
The components identified by mark
or
dotted line with mark are critical for
safety.
Replace only with part number specified.
Note :
The components identified by mark
contain confidential information. Strictly
follow the instructions whenever the
components are repaired and/or
replaced.
1 3-077-331-11 +BV3 (3-CR)
2 3-077-331-21 +BV3 (3-CR)
3 1-834-192-11 CABLE, FLEXIBLE FLAT (FMO-012)
* 4 1-834-190-11 CABLE, FLEXIBLE FLAT (FIM-018)
5 3-071-119-91 COVER, BATTERY
6 2-319-080-21 COVER, TRAY (SILVER)
(DVP-NS78H;AEP,UK,RUS)
6 2-319-080-31 COVER, TRAY (BLACK)
(DVP-NS78H;AEP,UK,RUS)
7 X-2178-183-1 PANEL ASSY, FRONT (SILVER)
(DVP-NS78H:AEP,UK,RUS)
7 X-2176-382-1 PANEL ASSY, FRONT (BLACK)
(DVP-NS78H:AEP,UK,RUS)
13 A-1268-921-A SERVICE ASSY, MV (DVP-NS78H:AEP,UK)
13 A-1269-083-A SERVICE ASSY, MV (DVP-NS78H:RUS)
* 14 1-833-760-11 CABLE, FLEXIBLE FLAT (FSW-003)
* 15 1-834-191-11 CABLE, FLEXIBLE FLAT (FMS-014)
16 3-087-053-01 +BVTP2.6 (3CR)
12 A-1224-253-A SERVICE ASSY, CASE UPPER (BLACK)
11 3-070-883-71 SCREW,TAPPING (BLACK)
12 A-1224-171-A SERVICE ASSY, CASE UPPER (SILVER)
(NS78H:AEP,RUS)
11 3-070-883-41 SCREW,TAPPING (SILVER)
8 1-474-062-11 POWER SUPPLY BLOCK
10
1-479-179-2
1 RIMOTE COMMANDER (RMT-D175P)
9 1-828-450-11 POWER-SUPPLY CORD
To Next Page
