Sony RMT-D175A - Electrical Parts List - MV-55 Board; IF-154 and MV-55 Board Components

8-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
R415 1-216-073-91 RES, CHIP 10K (2012)
R416 1-216-073-91 RES, CHIP 10K (2012)
R417 1-216-073-91 RES, CHIP 10K (2012)
R418 1-216-073-91 RES, CHIP 10K (2012)
R419 1-216-073-91 RES, CHIP 10K (2012)
R420 1-216-027-91 RES-CHIP 120 5% 1/10W
R421 1-216-013-91 RES-CHIP 33 5% 1/10W
R422 1-216-097-91 RES-CHIP 100K 5% 1/10W
R423 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R424 1-216-017-91 RES-CHIP 47 5% 1/10W
R426 1-216-073-91 RES, CHIP 10K (2012)
R427 1-216-083-91 RES-CHIP 27K 5% 1/10W
R433 1-216-073-91 RES, CHIP 10K (2012)
(DVP-NS77HP/NS78H:EXCEPT CND/NS78HP:E,BR)
R434 1-216-073-91 RES, CHIP 10K (2012)
(DVP-NS77HP/NS78H:EXCEPT CND/NS78HP:E,BR)
R436 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(DVP-NS78H:SP,KR,TH)
R436 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
(DVP-NS78H:AEP,UK)
R436 1-216-081-91 RES-CHIP 22K 5% 1/10W
(DVP-NS78H:RUS)
R436 1-216-073-91 RES, CHIP 10K (2012)
(DVP-NS72HP/NS77H/NS77HP/NS78H:CND/NS78HP:E,BR)
R437 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
(DVP-NS77HP:MX/NS78HP:E,BR)
R437 1-216-081-91 RES-CHIP 22K 5% 1/10W
(DVP-NS78H:RUS)
R437 1-216-073-91 RES, CHIP 10K (2012)
(DVP-NS72HP/NS77H:US/NS78H:CND,SP,KR,TH)
R439 1-216-073-91 RES, CHIP 10K (2012)
R442 1-216-017-91 RES-CHIP 47 5% 1/10W
R443 1-216-025-91 RES-CHIP 100 5% 1/10W
R444 1-216-025-91 RES-CHIP 100 5% 1/10W
R445 1-208-816-91 METAL CHIP 27K 0.5% 1/10W
R446 1-216-025-91 RES-CHIP 100 5% 1/10W
<TRANSFORMER>
* T401 01-445-125-11 DC-DC CONVERTER TRANSFORMER
<VIBRATOR>
X401 1-781-472-21 VIBRATOR, CERAMIC
A-1268-748-A SERVICE ASSY, MV-55 (NS77H)
A-1269-126-A SERVICE ASSY, MV-55 (DVP-NS77HP:MX)
A-1269-115-A SERVICE ASSY, MV-55 (DVP-NS78H:CND)
A-1269-132-A SERVICE ASSY, MV-55 (DVP-NS78HP:E)
A-1269-137-A SERVICE ASSY, MV-55 (DVP-NS78H:BR/NS78HP:BR)
A-1276-114-A SERVICE ASSY, MV-55 (DVP-NS78H:SP,KR,TH)
A-1443-600-A SERVICE ASSY, MV-55 (NS72HP)
<CAPACITOR>
C101 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C102 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C103 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C105 1-128-994-21 ELECT CHIP 47UF 20% 10V
C106 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C108 1-164-172-91 CERAMIC CHIP 0.0056UF 10.00% 25V
C109 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C1100 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1101 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1102 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C1103 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C111 1-128-994-21 ELECT CHIP 47UF 20% 10V
C112 1-128-994-21 ELECT CHIP 47UF 20% 10V
C113 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C114 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C115 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C116 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C117 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C118 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C119 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C120 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C121 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C122 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C123 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C124 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C125 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C126 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C127 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C128 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C129 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C130 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C131 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C132 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C133 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C134 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C135 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V
C136 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C137 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C138 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C139 1-162-919-91 CERAMIC CHIP 22PF 5.00% 50V
C140 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C141 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C142 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C143 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C144 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C145 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C147 1-165-176-91 CERAMIC CHIP 0.047UF 10.00% 16V
C148 1-165-176-91 CERAMIC CHIP 0.047UF 10.00% 16V
C149 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C150 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C151 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C152 1-162-918-91 CERAMIC CHIP 18PF 5.00% 50V
(DVP-NS72HP/NS77H:US/NS78H:CND)
C152 1-162-917-91 CERAMIC CHIP 15PF 5.00% 50V
(DVP-NS77HP:MX/NS78H:EXCEPT CND/NS78HP:E,BR)
C153 1-162-918-91 CERAMIC CHIP 18PF 5.00% 50V
(DVP-NS72HP/NS77H:US/NS78H:CND)
C153 1-162-917-91 CERAMIC CHIP 15PF 5.00% 50V
(DVP-NS77HP:MX/NS78H:EXCEPT CND/NS78HP:E,BR)
MV-55IF-154
Note :
The components identified by mark
contain confidential information. Strictly
follow the instructions whenever the
components are repaired and/or
replaced.
**************************
