8-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
R243 1-216-809-91 METAL CHIP 100 5% 1/10W
R246 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R247 1-216-821-91 METAL CHIP 1K 5% 1/10W
R321 1-216-833-91 METAL CHIP 10K 5% 1/10W
R322 1-216-864-91 SHORT CHIP 0
R327 1-216-833-91 METAL CHIP 10K 5% 1/10W
R331 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R332 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R333 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R334 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R335 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R336 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R347 1-216-864-91 SHORT CHIP 0
R348 1-216-864-91 SHORT CHIP 0
R349 1-216-864-91 SHORT CHIP 0
R350 1-216-864-91 SHORT CHIP 0
R351 1-216-864-91 SHORT CHIP 0
R388 1-216-864-91 SHORT CHIP 0
R389 1-216-864-91 SHORT CHIP 0
R390 1-216-864-91 SHORT CHIP 0
R393 1-216-864-91 SHORT CHIP 0
R394 1-216-864-91 SHORT CHIP 0
R398 1-216-864-91 SHORT CHIP 0
R399 1-216-864-91 SHORT CHIP 0
R401 1-218-865-91 METAL CHIP 5.6K 0.5% 1/10W
R402 1-216-845-91 METAL CHIP 100K 5% 1/10W
R404 1-218-865-91 METAL CHIP 5.6K 0.5% 1/10W
R405 1-216-864-91 SHORT CHIP 0
R406 1-216-864-91 SHORT CHIP 0
R409 1-218-864-91 METAL CHIP 5.1K 0.5% 1/10W
R410 1-218-864-91 METAL CHIP 5.1K 0.5% 1/10W
R411 1-218-883-91 METAL CHIP 33K 0.5% 1/10W
R412 1-218-883-91 METAL CHIP 33K 0.5% 1/10W
R413 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R414 1-216-817-91 METAL CHIP 470 5% 1/10W
R415 1-216-817-91 METAL CHIP 470 5% 1/10W
R416 1-216-830-91 METAL CHIP 5.6K 5% 1/10W
R417 1-216-833-91 METAL CHIP 10K 5% 1/10W
R418 1-216-845-91 METAL CHIP 100K 5% 1/10W
R419 1-216-849-91 METAL CHIP 220K 5% 1/10W
R420 1-216-817-91 METAL CHIP 470 5% 1/10W
R421 1-216-833-91 METAL CHIP 10K 5% 1/10W
R422 1-216-833-91 METAL CHIP 10K 5% 1/10W
R424 1-216-833-91 METAL CHIP 10K 5% 1/10W
R425 1-216-841-91 METAL CHIP 47K 5% 1/10W
R426 1-216-817-91 METAL CHIP 470 5% 1/10W
R427 1-216-817-91 METAL CHIP 470 5% 1/10W
R428 1-216-833-91 METAL CHIP 10K 5% 1/10W
R429 1-216-841-91 METAL CHIP 47K 5% 1/10W
R430 1-216-841-91 METAL CHIP 47K 5% 1/10W
R434 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R435 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R438 1-216-845-91 METAL CHIP 100K 5% 1/10W
R445 1-218-865-91 METAL CHIP 5.6K 0.5% 1/10W
R446 1-218-865-91 METAL CHIP 5.6K 0.5% 1/10W
R449 1-216-813-91 METAL CHIP 220 5% 1/10W
R451 1-216-807-91 METAL CHIP 68 5% 1/10W
R452 1-216-833-91 METAL CHIP 10K 5% 1/10W
R453 1-216-821-91 METAL CHIP 1K 5% 1/10W
R454 1-216-821-91 METAL CHIP 1K 5% 1/10W
R456 1-216-821-91 METAL CHIP 1K 5% 1/10W
R477 1-216-833-91 METAL CHIP 10K 5% 1/10W
R478 1-216-845-91 METAL CHIP 100K 5% 1/10W
R479 1-216-833-91 METAL CHIP 10K 5% 1/10W
R481 1-216-833-91 METAL CHIP 10K 5% 1/10W
R482 1-216-833-91 METAL CHIP 10K 5% 1/10W
R484 1-216-830-91 METAL CHIP 5.6K 5% 1/10W
R485 1-216-864-91 SHORT CHIP 0
R486 1-216-864-91 SHORT CHIP 0
R489 1-216-833-91 METAL CHIP 10K 5% 1/10W
R502 1-216-833-91 METAL CHIP 10K 5% 1/10W
R503 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R504 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R505 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R506 1-216-864-91 SHORT CHIP 0
R507 1-216-864-91 SHORT CHIP 0
R508 1-216-864-91 SHORT CHIP 0
R509 1-216-864-91 SHORT CHIP 0
<CONDUCTOR>
RB103 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB104 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB105 1-234-723-21 RES, NETWORK 75 (1005X4)
RB106 1-234-723-21 RES, NETWORK 75 (1005X4)
RB107 1-234-944-21 RES, NETWORK 47 (1005X4)
RB108 1-234-944-21 RES, NETWORK 47 (1005X4)
RB109 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB110 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB111 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB112 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB113 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB114 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB115 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
<CRYSTAL>
* X101 1-814-031-11 VIBRATOR, CRYSTAL
(DVP-NS72HP/NS77H:US/NS78H:CND)
X101 1-813-924-11 QUARTZ CRYSTAL UNIT
(DVP-NS77HP:MX/NS78H:EXCEPT CND/NS78HP:E,BR)
A-1268-921-A SERVICE ASSY, MV-56 (DVP-NS78H:AEP,UK)
A-1269-083-A SERVICE ASSY, MV-56 (DVP-NS78H:RUS)
********************
<CAPACITOR>
C101 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C102 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C103 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C105 1-128-994-21 ELECT CHIP 47UF 20% 10V
C106 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
MV-56MV-55
Note :
The components identified by mark
contain confidential information. Strictly
follow the instructions whenever the
components are repaired and/or
replaced.
To Next Page
