Sony RMT-D175A - MV-56 Board Components (Continued)

8-13
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
C335 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C401 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V
C402 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V
C405 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V
C406 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V
C407 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C408 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C409 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C410 1-128-994-21 ELECT CHIP 47UF 20% 10V
C411 1-128-994-21 ELECT CHIP 47UF 20% 10V
C413 1-128-397-21 ELECT CHIP 100UF 20% 16V
C415 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C416 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C421 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C423 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C424 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C428 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C429 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C444 1-126-204-21 ELECT CHIP 47UF 20.00% 16V
C501 1-128-994-21 ELECT CHIP 47UF 20% 10V
C502 1-128-994-21 ELECT CHIP 47UF 20% 10V
C504 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C505 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C506 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
<CONNECTOR>
CN102 1-821-398-11 HDMI CONNECTOR
* CN105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN201 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN501 1-564-009-11 PIN, CONNECTOR 10P
<DIODE>
D303 6-501-675-01 DIODE HZM6.8ZMWATL-E
D304 6-501-675-01 DIODE HZM6.8ZMWATL-E
D305 6-501-675-01 DIODE HZM6.8ZMWATL-E
D306 6-501-675-01 DIODE HZM6.8ZMWATL-E
D309 8-719-069-56 DIODE UDZSTE-176.2B
D310 8-719-083-63 DIODE UDZSTE-1713B
D311 6-501-675-01 DIODE HZM6.8ZMWATL-E
D312 6-501-675-01 DIODE HZM6.8ZMWATL-E
D313 6-501-675-01 DIODE HZM6.8ZMWATL-E
D314 6-501-675-01 DIODE HZM6.8ZMWATL-E
D315 8-719-988-61 DIODE 1SS355TE-17
D401 6-500-335-01 DIODE MC2838-T112-1
D402 6-500-334-01 DIODE MC2836-T112-1
D404 8-719-988-61 DIODE 1SS355TE-17
<FERRITE>
FB106 1-469-324-21 FERRITE 0UH
FB107 1-469-324-21 FERRITE 0UH
FB108 1-469-324-21 FERRITE 0UH
FB109 1-400-382-21 FERRITE 0UH
FB111 1-469-670-21 FERRITE 0UH
FB112 1-469-670-21 FERRITE 0UH
FB115 1-400-382-21 FERRITE 0UH
FB116 1-414-226-21 FERRITE 0UH
FB117 1-469-118-21 FERRITE 0UH
FB118 1-469-118-21 FERRITE 0UH
FB119 1-469-118-21 FERRITE 0UH
FB120 1-469-118-21 FERRITE 0UH
FB121 1-469-118-21 FERRITE 0UH
FB122 1-469-118-21 FERRITE 0UH
FB123 1-400-382-21 FERRITE 0UH
FB124 1-469-670-21 FERRITE 0UH
FB501 1-469-324-21 FERRITE 0UH
FB502 1-469-324-21 FERRITE 0UH
FB503 1-469-324-21 FERRITE 0UH
FB504 1-469-324-21 FERRITE 0UH
FB505 1-469-324-21 FERRITE 0UH
FB506 1-469-324-21 FERRITE 0UH
<IC>
IC103 IC (EEPROM) (Refer to notes)
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-706-487-01 IC TC7SH08FU(T5RSOYJF)
IC107 6-702-302-01 IC TK11133CSCL-G
IC108 6-703-224-01 IC S-80828CNNB-B8NT2G
IC109 6-705-337-01 IC TK11150CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC111 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC303 8-759-667-17 IC L79M05TLL-SONY-TL-E
IC305 6-706-453-01 IC NJM2587V(TE2)
IC401 8-759-100-96 IC UPC4558G2
IC402 6-703-597-01 IC BD4830G-TR
<INDUCTOR>
LF101 1-457-374-21 INDUCTOR 0UH
LF102 1-457-374-21 INDUCTOR 0UH
LF104 1-457-374-21 INDUCTOR 0UH
<FUSE>
* PS501 1-576-892-11 FUSE 1A 32V
* PS502 1-576-892-11 FUSE 1A 32V
<TRANSISTOR>
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-424-63 TRANSISTOR UN2212-TX
Q104 6-550-008-01 TRANSISTOR UM6K1N-TN
Q105 8-729-028-27 TRANSISTOR 2SK2009(TE85L)
Note :
The components identified by mark
or
dotted line with mark are critical for
safety.
Replace only with part number specified.
MV-56
Notes:
Special keys have been written in IC103 (HDCP & CPRM keys)
and therefore the IC103 cannot be replaced.
If this IC is faulty, replace the board entirely.
IC101 6-711-269-01 IC CXD9894R
