Specifications : UBP-X800 EC1/CEK/AU2
Specifications and design are subject to change without notice.
System
Inputs and outputs
Wireless
Bluetooth
Laser Semiconductor laser
Jack name Jack type/Output level/Load impedance
DIGITAL OUT (COAXIAL) Phono jack /0.5 Vp-p/75 ohms
HDMI OUT 1*/2
HDMI 19-pin standard connector
* Only HDMI OUT 1 supports 4K and video output.
LAN (100) 100BASE-TX Terminal
USB
USB jack Type A (For connecting a USB memory, memory
card reader, digital still camera, and digital video
camera)*
* Do not use for power charging purposes.
Wireless LAN standard Protocol IEEE802.11 a/b/g/n
Frequency range 2.4 GHz, 5 GHz band
Modulation DSSS and OFDM
Bluetooth Version Bluetooth Specification v4.1
Communication system Bluetooth Specification v4.1
Output Bluetooth Specification Power Class 1
Maximum communication
range
Line of sight approx. 30 m
Frequency band 2.4 GHz
Modulation method FHSS
Compatible Bluetooth Profiles
A2DP v1.2, AVRCP v1.3
Supported Codecs SBC, AAC, LDAC
Transmission range (A2DP)
•20 Hz - 40,000 Hz (LDAC in sampling 96 kHz and
transmit by 990 kbps)
•20 Hz - 20,000 Hz (in sampling 44.1 kHz)
General
Power requirements Rating: Input 220 V - 240 V AC, 50/60 Hz
Power consumption 15 W
Network standby Less than 2 W (all wired/wireless network ports ON)
Dimensions (approx.)
430 mm × 265 mm × 50 mm
(width × depth × height) incl. projecting parts
Mass (approx.) 3.8 kg
Operating temperature 5 ºC to 35 ºC
Operating humidity 25 % to 80 %
ii
