6-5
Audio does not sound right?
Video is output properly? To Video section flowchart
To Main Flowchart
To Drive Flowchart
Check SW3.3V To Power Supply Flowchart
Is there HDMI output?
Replace MB Board
To Main Flowchart
Is the Drive operation
properly?
Is there AUDIO digital signal
(SPDIF) input to SPDIF
circuit?
--------------------------------------
IC101 (CXD90049GG-BA) :
B11 SPDIF
Check SPDIF output resistor/
Capacitor OK?
--------------------------------------
R1037 / R1053 / R1054 /
R1056 / R1057 / R1059 /
R1060 / R1061 / R1007 /
R1011
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
6-7. Audio (SPDIF) Section Flowchart
To Next Page
