4-11. PRINTED WIRING BOARD — MD-94 BOARD SECTION —
• See page 7 for Circuit Boards Location. :Uses unleaded solder.
SE-130 BOARD
MD-94 BOARD
(13)
13
(13)
13
MAIN BOARD
CN704
(Page 11)
D
M
M001
TURN TABLE
MOTOR
M
LOADING
MOTOR
ROTARY
ENCODER
CN001
CN101
PH102
PH101
CN102
CN003CN004
S001
CN002
