Sony SCD-CE595 - Electrical Parts List; Component Listings (Capacitors, Connectors, ICs, etc.)

27
SCD-CE595
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
CND : Canadian model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4752-651-A DISPLAY BOARD, COMPLETE
************************
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C801 1-124-584-00 ELECT 100uF 20% 6.3V
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C804 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C806 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C811 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C812 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C817 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C818 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C819 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C821 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C822 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C823 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C824 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C825 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C827 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C829 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C831 1-124-589-11 ELECT 47uF 20% 6.3V
C832 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN801 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< FERRITE BEAD >
FB801 1-414-595-11 INDUCTOR, FERRITE BEAD
< FLUORESCENT INDICATOR TUBE >
FL801 1-518-992-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 6-804-318-01 IC uPD780232GC-706-8BT-A
IC802 8-759-826-33 IC NJL73H400A ( )
< TRANSISTOR >
Q821 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q822 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q823 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q824 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q825 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q826 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
< RESISTOR >
R805 1-216-833-11 METAL CHIP 10K 5% 1/10W
R817 1-216-833-11 METAL CHIP 10K 5% 1/10W
R818 1-216-833-11 METAL CHIP 10K 5% 1/10W
R819 1-216-833-11 METAL CHIP 10K 5% 1/10W
R820 1-216-833-11 METAL CHIP 10K 5% 1/10W
R821 1-216-845-11 METAL CHIP 100K 5% 1/10W
R822 1-216-845-11 METAL CHIP 100K 5% 1/10W
R823 1-216-845-11 METAL CHIP 100K 5% 1/10W
R824 1-216-845-11 METAL CHIP 100K 5% 1/10W
R825 1-216-845-11 METAL CHIP 100K 5% 1/10W
R826 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-805-11 METAL CHIP 47 5% 1/10W
R832 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-821-11 METAL CHIP 1K 5% 1/10W
R842 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R843 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R844 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R845 1-216-833-11 METAL CHIP 10K 5% 1/10W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R856 1-216-833-11 METAL CHIP 10K 5% 1/10W
R857 1-216-833-11 METAL CHIP 10K 5% 1/10W
R858 1-216-808-11 METAL CHIP 82 5% 1/10W
< SWITCH >
S841 1-762-875-21 SWITCH, KEYBOARD (x)
S842 1-762-875-21 SWITCH, KEYBOARD (H)
S843 1-762-875-21 SWITCH, KEYBOARD (X)
S844 1-762-875-21 SWITCH, KEYBOARD (m)
S845 1-762-875-21 SWITCH, KEYBOARD (M)
S851 1-762-875-21 SWITCH, KEYBOARD (A)
S852 1-762-875-21 SWITCH, KEYBOARD (EX-CHANGE)
DISPLAY
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
• Accessories are given in the last of this parts
list.
