Sony SCD-CE595 - Key, LED Board, and Other Component Listings

28
SCD-CE595
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S853 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S855 1-478-268-11 ENCODER, ROTARY
(. AMS >)(PUSH ENTER)
< VIBRATOR >
X801 1-795-058-21 VIBRATOR, CERAMIC 5MHz
************************************************************
1-862-173-11 KEY BOARD
**********
< CONNECTOR >
CN813 1-506-468-11 PIN, CONNECTOR 3P
< RESISTOR >
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R863 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R864 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R871 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R873 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R874 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S861 1-762-875-21 SWITCH, KEYBOARD (MENU)
S862 1-762-875-21 SWITCH, KEYBOARD (SA-CD/CD)
S863 1-762-875-21 SWITCH, KEYBOARD (MULITI/2CH)
S864 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S865 1-762-875-21 SWITCH, KEYBOARD (TIME/TEXT)
S871 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S872 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S873 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S874 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S875 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
************************************************************
1-862-174-11 LED BOARD
**********
< CAPACITOR >
C833 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN814 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D801 6-500-647-01 DIODE SEL5E20C-STP15
< RESISTOR >
R834 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
A-4752-598-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C201 1-126-916-11 ELECT 1000uF 20% 6.3V
C202 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-115-156-11 CERAMIC CHIP 1uF 10V
C212 1-128-991-21 ELECT CHIP 10uF 20% 50V
C236 1-115-156-11 CERAMIC CHIP 1uF 10V
C238 1-115-156-11 CERAMIC CHIP 1uF 10V
C242 1-128-991-21 ELECT CHIP 10uF 20% 50V
C266 1-115-156-11 CERAMIC CHIP 1uF 10V
C268 1-115-156-11 CERAMIC CHIP 1uF 10V
C272 1-128-991-21 ELECT CHIP 10uF 20% 50V
C281 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C305 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C321 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C322 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C324 1-115-156-11 CERAMIC CHIP 1uF 10V
C325 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C331 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C351 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C362 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C364 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C366 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C403 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C404 1-115-156-11 CERAMIC CHIP 1uF 10V
C405 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C406 1-128-992-21 ELECT CHIP 47uF 20% 25V
C432 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C433 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C434 1-115-156-11 CERAMIC CHIP 1uF 10V
C435 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C436 1-128-992-21 ELECT CHIP 47uF 20% 25V
C462 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C463 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C464 1-115-156-11 CERAMIC CHIP 1uF 10V
C465 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C466 1-128-992-21 ELECT CHIP 47uF 20% 25V
C502 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C503 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C504 1-115-156-11 CERAMIC CHIP 1uF 10V
C505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C506 1-128-992-21 ELECT CHIP 47uF 20% 25V
C532 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C533 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C534 1-115-156-11 CERAMIC CHIP 1uF 10V
C535 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C536 1-128-992-21 ELECT CHIP 47uF 20% 25V
C562 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C563 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C564 1-115-156-11 CERAMIC CHIP 1uF 10V
C565 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C566 1-128-992-21 ELECT CHIP 47uF 20% 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C703 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C704 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C705 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DISPLAY MAINKEY LED
