Sony SCD-CE595 - Main Board Components (Diodes, Jacks, Transistors, Resistors, ICs)

30
SCD-CE595
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN703 1-793-989-21 CONNECTOR, FFC/FPC 13P
CN901 1-784-924-11 PIN, CONNECTOR 8P
< DIODE >
D321 8-719-027-76 DIODE 1SS357-TPH3
D509 8-719-941-09 DIODE DAP202UT106
D511 8-719-941-09 DIODE DAP202UT106
D703 8-719-069-54 DIODE UDZSTE-175.1B
D921 8-719-053-18 DIODE 1SR154-400TE-25
D922 8-719-053-18 DIODE 1SR154-400TE-25
D923 8-719-053-18 DIODE 1SR154-400TE-25
D924 8-719-053-18 DIODE 1SR154-400TE-25
D931 8-719-053-18 DIODE 1SR154-400TE-25
D932 8-719-053-18 DIODE 1SR154-400TE-25
D933 8-719-053-18 DIODE 1SR154-400TE-25
D934 8-719-053-18 DIODE 1SR154-400TE-25
D936 8-719-053-18 DIODE 1SR154-400TE-25
D937 8-719-053-18 DIODE 1SR154-400TE-25
D960 8-719-941-86 DIODE DAN202UT106
D961 8-719-941-86 DIODE DAN202UT106
D963 6-500-696-01 DIODE UDZSTE-173.0B
D971 8-719-053-18 DIODE 1SR154-400TE-25
D972 8-719-083-87 DIODE UDZS-TE17-33B
D973 8-719-069-60 DIODE UDZSTE-179.1B
< GROUND TERMINAL BOARD >
ETP910 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB201 1-500-283-11 INDUCTOR, FERRITE BEAD
FB703 1-414-595-11 INDUCTOR, FERRITE BEAD
FB710 1-414-595-11 INDUCTOR, FERRITE BEAD
< FILTER >
FL606 1-234-177-21 FILTER, CHIP EMI
< IC >
IC200 6-703-420-01 IC DSD1751DBQR
IC230 6-703-420-01 IC DSD1751DBQR
IC260 6-703-420-01 IC DSD1751DBQR
IC320 8-759-549-25 IC SN74LVU04APWR
IC330 6-600-012-01 IC TOTX141L
IC400 8-759-710-97 IC NJM4565M (TE2)
IC430 8-759-710-97 IC NJM4565M (TE2)
IC460 8-759-710-97 IC NJM4565M (TE2)
IC701 8-759-636-64 IC M51957BFP-600C
* IC702 6-703-671-01 IC BR9040F-WE2
IC703 6-700-398-01 IC uPC2918T-E1
IC705 6-804-317-01 IC HD6432238RN51TEV
IC706 8-752-420-59 IC CXD2754Q
IC708 6-702-336-01 IC MSM56V16160F-8TK7R1
IC710 8-759-598-69 IC BA6956AN
IC712 6-702-157-01 IC FAN8035L
IC920 6-705-463-01 IC BA33BC0T
IC950 6-705-469-01 IC BA50BC0FP-E2
IC985 8-759-460-81 IC BA12FP-E2
< JACK >
J351 1-785-536-11 JACK, PIN 6P (5.1CH OUT)(ANALOG)
< TRANSISTOR >
Q301 8-729-924-04 TRANSISTOR UN5116-TX
Q303 8-729-924-04 TRANSISTOR UN5116-TX
Q305 8-729-924-04 TRANSISTOR UN5116-TX
Q401 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q402 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q431 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q432 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q462 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q463 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q501 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q502 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q531 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q532 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q562 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q563 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q701 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q961 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q971 8-729-019-72 TRANSISTOR 2SB1260T100
< RESISTOR >
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
R202 1-216-839-11 METAL CHIP 33K 5% 1/10W
R321 1-216-857-11 METAL CHIP 1M 5% 1/10W
R322 1-216-864-11 SHORT CHIP 0
R323 1-216-821-11 METAL CHIP 1K 5% 1/10W
R324 1-216-809-11 METAL CHIP 100 5% 1/10W
R326 1-216-801-11 METAL CHIP 22 5% 1/10W
R328 1-216-801-11 METAL CHIP 22 5% 1/10W
R330 1-216-801-11 METAL CHIP 22 5% 1/10W
R404 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R407 1-216-845-11 METAL CHIP 100K 5% 1/10W
R408 1-216-815-11 METAL CHIP 330 5% 1/10W
R409 1-216-813-11 METAL CHIP 220 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R434 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R437 1-216-845-11 METAL CHIP 100K 5% 1/10W
R438 1-216-815-11 METAL CHIP 330 5% 1/10W
R439 1-216-813-11 METAL CHIP 220 5% 1/10W
R464 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R467 1-216-845-11 METAL CHIP 100K 5% 1/10W
R468 1-216-815-11 METAL CHIP 330 5% 1/10W
R469 1-216-813-11 METAL CHIP 220 5% 1/10W
R504 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R507 1-216-845-11 METAL CHIP 100K 5% 1/10W
R508 1-216-815-11 METAL CHIP 330 5% 1/10W
R509 1-216-813-11 METAL CHIP 220 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R534 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R537 1-216-845-11 METAL CHIP 100K 5% 1/10W
R538 1-216-815-11 METAL CHIP 330 5% 1/10W
R539 1-216-813-11 METAL CHIP 220 5% 1/10W
MAIN
