7-6
7-2. ELECTRICAL PARTS LIST
Note:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-6794-482-A DS-79S BOARD, COMPLETE
**********************
(478,677HF,678HF,688HF)
* A-6794-503-A DS-79SX BOARD, COMPLETE
***********************
(L47,L48,L67HF,L68HF,X60HF)
* A-6794-509-A DS-79D BOARD, COMPLETE
**********************
(L57,L58,L77HF,L78HF,X50)
(Ref.No.:1,000 Series)
< CONNECTOR >
CN442 1-774-471-41 CONNECTOR, FFC/FPC 5P
(L57,L58,L77HF,L78HF,X50)
< DIODE >
D441 8-719-056-06 DIODE SLR-342DCT31
(L57,L58,L77HF,L78HF,X50)
< JUMPER RESISTOR >
JR702 1-216-296-00 METAL CHIP 0 5% 1/8W
JR703 1-216-296-00 METAL CHIP 0 5% 1/8W
JR704 1-216-296-00 METAL CHIP 0 5% 1/8W
JR705 1-216-296-00 METAL CHIP 0 5% 1/8W
JR706 1-216-295-00 METAL CHIP 0 5% 1/10W
JR707 1-216-295-00 METAL CHIP 0 5% 1/10W
JR708 1-216-296-00 METAL CHIP 0 5% 1/8W
JR709 1-216-296-00 METAL CHIP 0 5% 1/8W
< RESISTOR >
R451 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R452 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R454 1-216-037-00 METAL CHIP 330 5% 1/10W
(L57,L58,L77HF,L78HF,X50)
< SWITCH >
S441 1-571-977-11 SWITCH, TACTIL (FF)
(L57,L58,L77HF,L78HF,X50)
S442 1-571-977-11 SWITCH, TACTIL (PLAY)
(EXCEPT L57,L58,L77HF,L78HF,X50)
S443 1-571-977-11 SWITCH, TACTIL (STOP)
(EXCEPT L57,L58,L77HF,L78HF,X50)
S444 1-571-977-11 SWITCH, TACTIL (REW)
(EXCEPT L57,L58,L77HF,L78HF,X50)
S445 1-571-977-11 SWITCH, TACTIL (JOG)
(L57,L58,L77HF,L78HF,X50)
S446 1-571-977-11 SWITCH, TACTIL (FF)
(EXCEPT L57,L58,L77HF,L78HF,X50)
S447 1-571-977-11 SWITCH, TACTIL (REW)
(L57,L58,L77HF,L78HF,X50)
* A-6794-483-A JK-161 BOARD, COMPLETE (688HF)
**********************
* A-6794-508-A JK-161MX BOARD, COMPLETE (L57,L58,X50)
************************
* A-6794-510-A JK-161HX BOARD, COMPLETE (L77HF,L78HF)
************************
(Ref.No.:2,000 Series)
< CAPACITOR >
C803 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(688HF,L57,L58,L77HF,L78HF,X50)
C805 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(688HF,L77HF,L78HF)
C806 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(688HF,L57,L58,L77HF,L78HF,X50)
< PIN JACK >
CJ801 1-774-509-11 JACK, PIN 3P (LINE 2 IN)
(688HF,L77HF,L78HF)
CJ801 1-774-510-11 JACK, PIN 2P (LINE 2 IN)
(L57,L58,X50)
< CONNECTOR >
CN801 1-506-469-11 PIN, CONNECTOR 4P (L57,L58,X50)
CN801 1-506-470-11 PIN, CONNECTOR 5P (688HF,L77HF,L78HF)
< DIODE >
D801 8-719-110-08 DIODE RD8.2ES-B2
(688HF,L57,L58,L77HF,L78HF,X50)
D802 8-719-110-08 DIODE RD8.2ES-B2 (688HF,L77HF,L78HF)
D803 8-719-109-84 DIODE RD5.1ES-B1
(688HF,L57,L58,L77HF,L78HF,X50)
D804 8-719-110-08 DIODE RD8.2ES-B2
(688HF,L57,L58,L77HF,L78HF,X50)
D805 8-719-110-08 DIODE RD8.2ES-B2
(688HF,L57,L58,L77HF,L78HF,X50)
D806 8-719-110-08 DIODE RD8.2ES-B2 (688HF,L77HF,L78HF)
D807 8-719-110-08 DIODE RD8.2ES-B2
(688HF,L57,L58,L77HF,L78HF,X50)
< JUMPER RESISTOR >
JS801 1-216-295-00 METAL CHIP 0 5% 1/10W
(L57,L58,X50)
JK-161DS-79
