5-7
5-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board naame.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FR-119
* A-6790-203-A DM-62 BOARD, COMPLETE
**********************
(Ref.No.: 3,000 Series)
< CONNECTOR >
CN440 1-695-947-11 CONNECTOR, BOARD TO BOARD 10P
CN441 1-774-471-41 CONNECTOR, FFC/FPC 5P(570)
< RESISTOR >
R440 1-216-073-00 METAL GLAZE 10K 5% 1/10W
R455 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W
R456 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W
R458 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W
R459 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W
R461 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R462 1-216-073-00 METAL GLAZE 10K 5% 1/10W
R463 1-216-073-00 METAL GLAZE 10K 5% 1/10W
< SWITCH >
S441 1-571-977-11 SWITCH, TACTIL(EJECT)
S442 1-571-977-11 SWITCH, TACTIL(REW)(570)
S443 1-571-977-11 SWITCH, TACTIL(FF)(570)
S444 1-571-977-11 SWITCH, TACTIL(PAUSE)
S445 1-571-977-11 SWITCH, TACTIL(REC)
S447 1-571-977-11 SWITCH, TACTIL(REW)(EXCEPT 570)
S448 1-571-977-11 SWITCH, TACTIL(FF)(EXCEPT 570)
S449 1-571-977-11 SWITCH, TACTIL(STOP)(EXCEPT 570)
S450 1-571-977-11 SWITCH, TACTIL(PLAY)(EXCEPT 570)
* A-6791-182-A FR-119 BOARD, COMPLETE (720VP)
**********************
* A-6791-184-A FR-119 BOARD, COMPLETE (720UX)
**********************
* A-6791-188-A FR-119 BOARD, COMPLETE (717VC,720VC)
**********************
* A-6791-191-A FR-119 BOARD, COMPLETE (715B,720B)
**********************
* A-6791-193-A FR-119 BOARD, COMPLETE (720EE)
**********************
* A-6791-195-A FR-119 BOARD, COMPLETE (720EX)
**********************
* A-6791-197-A FR-119 BOARD, COMPLETE (720NP)
**********************
* A-6791-199-A FR-119 BOARD, COMPLETE (720NC,725NC)
**********************
* A-6791-202-A FR-119 BOARD, COMPLETE (570EG)
**********************
* A-6791-205-A FR-119 BOARD, COMPLETE (570EE)
**********************
* A-6791-208-A FR-119 BOARD, COMPLETE (720EG)
**********************
* A-6791-209-A FR-119 BOARD, COMPLETE (720BZ)
**********************
* A-6791-213-A FR-119 BOARD, COMPLETE (325)
**********************
* A-6791-216-A FR-119 BOARD, COMPLETE (475)
**********************
(Ref.No.: 3,000 Series)
* 3-972-888-01 HOLDER (85), FL
< CAPACITOR >
C400 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C401 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(570)
C403 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(570)
C408 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C471 1-126-924-11 ELECT 330uF 20% 10V
C472 1-126-916-11 ELECT 1000uF 20% 6.3V
C473 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C474 1-125-705-11 CAPACITOR 0.22F 0 5.5V
C475 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C476 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C477 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C478 1-164-159-21 CERAMIC 0.1uF 50V
C479 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C480 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C481 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C482 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C483 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C485 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C489 1-163-031-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
* CN401 1-691-407-11 CONNECTOR, BOARD TO BOARD 10P
CN402 1-695-390-31 PIN, CONNECTOR (PC BOARD) 29P
CN403 1-506-470-11 PIN, CONNECTOR 5P (570)
< DIODE >
D401 8-719-108-12 DIODE RD9.1E-W (570)
D403 8-719-108-12 DIODE RD9.1E-W (570)
D405 8-719-056-07 DIODE SLR-342MC-A-47
D408 8-719-110-08 DIODE RD8.2ES-B2
D470 8-719-200-82 DIODE 11ES2
D471 8-719-200-82 DIODE 11ES2
< TERMINAL BOARD >
ET400 1-537-770-21 TERMINAL BOARD, GROUND (570)
DM-62
To Next Page
