5-11
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C925 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(715B,717VC,720B,720BZ,720NP,720VC)
C926 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C927 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C928 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C930 1-126-967-11 ELECT 47uF 20% 16V
(715B,717VC,720B,720BZ,720NP,720VC)
C931 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(715B,717VC,720B,720BZ,720NP,720VC)
C932 1-126-933-11 ELECT 100uF 20% 16V
(715B,717VC,720B,720BZ,720NP,720VC)
C933 1-126-964-11 ELECT 10uF 20% 50V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C934 1-126-964-11 ELECT 10uF 20% 50V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C935 1-126-964-11 ELECT 10uF 20% 50V
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
C936 1-126-964-11 ELECT 10uF 20% 50V
(715B,717VC,720B,720BZ,720NP,720VC)
C937 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(715B,717VC,720B,720BZ,720NP,720VC)
C938 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(715B,717VC,720B,720BZ,720NP,720VC)
C951 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
(EXCEPT 325,475,570EE,720EG,720EE)
< CONNECTOR >
CN101 1-506-470-11 PIN, CONNECTOR 5P
* CN102 1-766-538-11 CONNECTOR, BOARD TO BOARD 8P
* CN103 1-766-537-11 CONNECTOR (HMD) 5P
* CN104 1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
CN161 1-506-470-11 PIN, CONNECTOR 5P (570)
CN163 1-695-352-11 PIN, CONNECTOR (PC BOARD) 29P
CN164 1-506-469-11 PIN, CONNECTOR 4P
CN305 1-573-852-11 CONNECTOR, BOARD TO BOARD 20P
CN306 1-766-718-11 CONNECTOR, BOARD TO BOARD 17P
CN540 1-568-016-21 SOCKET, PIN 21P(LINE-1(TV))
CN600 1-569-338-11 CONNECTOR, BOARD TO BOARD 19P
CN930 1-568-016-21 SOCKET, PIN 21P(DECODER/LINE-2 IN)
(EXCEPT 325,475,570EE,720EE,720EG)
< TRIMMER >
CT500 1-141-334-11 CAP, TRIMMER 30PF
< DIODE >
D100 8-719-048-26 DIODE GL528V1
D107 8-719-911-19 DIODE 1SS119
D108 8-719-200-82 DIODE 11ES2
D131 8-719-200-82 DIODE 11ES2
D160 8-719-200-82 DIODE 11ES2
D301 8-719-911-19 DIODE 1SS119 (325,475,570)
D361 8-719-911-19 DIODE 1SS119
D501 8-719-911-19 DIODE 1SS119
D502 8-719-911-19 DIODE 1SS119
D503 8-719-911-19 DIODE 1SS119
D540 8-719-109-97 DIODE RD6.8ES-B2
D541 8-719-109-97 DIODE RD6.8ES-B2
D542 8-719-109-97 DIODE RD6.8ES-B2 (715B,717VC,720,725)
D543 8-719-109-97 DIODE RD6.8ES-B2
D544 8-719-109-97 DIODE RD6.8ES-B2 (715B,717VC,720,725)
D545 8-719-109-97 DIODE RD6.8ES-B2
D546 8-719-109-97 DIODE RD6.8ES-B2 (715B,717VC,720,725)
D547 8-719-109-97 DIODE RD6.8ES-B2 (715B,717VC,720,725)
D548 8-719-109-97 DIODE RD6.8ES-B2
D549 8-719-109-97 DIODE RD6.8ES-B2
D551 8-719-109-97 DIODE RD6.8ES-B2
(715B,717VC,720B,720BZ,720NP,720VC)
D552 8-719-921-86 DIODE MTZJ-13
D553 8-719-109-97 DIODE RD6.8ES-B2
D554 8-719-109-97 DIODE RD6.8ES-B2
D700 8-719-911-19 DIODE 1SS119
D701 8-719-800-76 DIODE 1SS226
D702 8-719-982-26 DIODE MTZJ-33B
D703 8-719-109-85 DIODE RD5.1ES-B2
D704 8-719-911-19 DIODE 1SS119
D930 8-719-200-82 DIODE 11ES2
(715B,717VC,720B,720BZ,720NP,720VC)
D932 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D933 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D934 8-719-109-97 DIODE RD6.8ES-B2
(715B,717VC,720B,720BZ,720NP,720VC)
D935 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D936 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D937 8-719-109-97 DIODE RD6.8ES-B2
(715B,717VC,720B,720BZ,720NP,720VC)
D938 8-719-109-97 DIODE RD6.8ES-B2
(715B,717VC,720B,720BZ,720NP,720VC)
D939 8-719-109-97 DIODE RD6.8ES-B2
(715B,717VC,720B,720BZ,720NP,720VC)
D940 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D941 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D942 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D943 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT 325,475,570EE,720EE,720EG)
D944 8-719-109-97 DIODE RD6.8ES-B2
D945 8-719-982-09 DIODE MTZJ-T-77-4.3
(EXCEPT 325,475,570EE,720EE,720EG)
< FILTER >
FL540 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720,725)
FL541 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720,725)
FL542 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720,725)
FL543 1-236-163-11 ENCAPSULATED COMPONENT
FL544 1-236-163-11 ENCAPSULATED COMPONENT
FL545 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720,725)
FL930 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT 325,475,570EE,720EE,720EG)
FL931 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT 325,475,570EE,720EE,720EG)
FL932 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720B,720BZ,720NP,720VC)
FL933 1-236-163-11 ENCAPSULATED COMPONENT
(715B,717VC,720B,720BZ,720NP,720VC)
MA-286
