Sony SLV-E325EG - Page 34

5-13
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
JS385 1-216-295-91 CONDUCTOR, CHIP(2012)(325,475,570)
JS389 1-216-295-91 CONDUCTOR, CHIP(2012)
(715B,717VC,720,725)
JS390 1-216-295-91 CONDUCTOR, CHIP(2012)(325,475,570)
JS392 1-216-295-91 CONDUCTOR, CHIP(2012)(570EG)
JS393 1-216-296-91 CONDUCTOR, CHIP(3216)(570EG)
JS540 1-216-296-91 CONDUCTOR, CHIP(3216)(325,475,570)
JS541 1-216-295-91 CONDUCTOR, CHIP(2012)(325,475,570)
JS700 1-216-296-91 CONDUCTOR, CHIP(3216)(720EE)
JS701 1-216-295-91 CONDUCTOR, CHIP(2012)(720EE)
JS805 1-216-295-91 CONDUCTOR, CHIP(2012)
JS924 1-216-055-00 METAL CHIP 1.8K 5% 1/10W (570EG)
JS925 1-216-295-91 CONDUCTOR, CHIP(2012)(570EG)
JS930 1-216-295-91 CONDUCTOR, CHIP(2012)(570EG)
JS931 1-216-295-91 CONDUCTOR, CHIP(2012)
(715B,720B,720BZ,720NP,720VC)
JS932 1-216-296-91 CONDUCTOR, CHIP(3216)(570EG)
< COIL >
L101 1-408-982-11 INDUCTOR 100uH
L161 1-408-970-21 INDUCTOR 10uH
L201 1-408-977-21 INDUCTOR 39uH
L202 1-408-982-11 INDUCTOR 100uH
L203 1-410-330-31 INDUCTOR 22uH (715B,720B,720BZ)
L204 1-408-970-21 INDUCTOR 10uH
L205 1-408-982-11 INDUCTOR 100uH
L206 1-408-970-21 INDUCTOR 10uH
L207 1-408-970-21 INDUCTOR 10uH
L291 1-408-982-11 INDUCTOR 100uH (715B,720B,720BZ)
L292 1-410-328-31 INDUCTOR 10uH (715B,720B,720BZ)
L301 1-408-982-11 INDUCTOR 100uH
L361 1-408-982-11 INDUCTOR 100uH (715B,717VC,720,725)
L500 1-408-982-11 INDUCTOR 100uH
L501 1-408-982-11 INDUCTOR 100uH
L502 1-410-506-11 INDUCTOR 5.6uH
L503 1-410-513-11 INDUCTOR 22uH
(325,475,570,715B,720B,720BZ,720EE,720EG)
L540 1-408-982-11 INDUCTOR 100uH
L700 1-408-982-11 INDUCTOR 100uH
L701 1-408-962-21 INDUCTOR 2.2uH
L702 1-408-962-21 INDUCTOR 2.2uH
L703 1-408-962-21 INDUCTOR 2.2uH
L930 1-408-982-11 INDUCTOR 100uH
(715B,717VC,720B,720BZ,720NP,720VC)
L931 1-408-982-11 INDUCTOR 100uH
(570EG,715B,717VC,720,725)
< PHOTO INTERRUPTER >
PH100 8-749-010-19 PHOTO INTERRUPTER GP3S113
PH101 8-749-010-20 PHOTO INTERRUPTER GP3S114
< IC LINK >
! PS130 1-533-586-31 LINK, IC 0.315A
< TRANSISTOR >
Q100 8-729-025-92 PHOTO TRANSISTOR PT380F
Q101 8-729-025-92 PHOTO TRANSISTOR PT380F
Q102 8-729-281-53 TRANSISTOR 2SC1815-GR
Q201 8-729-230-49 TRANSISTOR 2SC2712-YG
Q202 8-729-230-49 TRANSISTOR 2SC2712-YG
Q203 8-729-421-19 TRANSISTOR UN2213 (EXCEPT 325)
Q205 8-729-421-19 TRANSISTOR UN2213 (715B,720B,720BZ)
Q208 8-729-422-27 TRANSISTOR 2SD601A-Q
Q209 8-729-216-22 TRANSISTOR 2SA1162-G
Q210 8-729-422-27 TRANSISTOR 2SD601A-Q
Q211 8-729-422-27 TRANSISTOR 2SD601A-Q
Q291 8-729-421-19 TRANSISTOR UN2213 (715B,720B,720BZ)
Q292 8-729-901-06 TRANSISTOR DTA144EK (715B,720B,720BZ)
Q293 8-729-421-19 TRANSISTOR UN2213 (715B,720B,720BZ)
Q301 8-729-422-27 TRANSISTOR 2SD601A-Q
Q361 8-729-422-27 TRANSISTOR 2SD601A-Q
(715B,717VC,720,725)
Q362 8-729-422-27 TRANSISTOR 2SD601A-Q
(715B,717VC,720,725)
Q362 8-729-424-67 TRANSISTOR UN2216 (325,475,570)
Q363 8-729-422-27 TRANSISTOR 2SD601A-Q
(715B,717VC,720,725)
Q364 8-729-216-22 TRANSISTOR 2SA1162-G
(715B,717VC,720,725)
Q500 8-729-216-22 TRANSISTOR 2SA1162-G
Q501 8-729-216-22 TRANSISTOR 2SA1162-G
Q502 8-729-216-22 TRANSISTOR 2SA1162-G
Q505 8-729-216-22 TRANSISTOR 2SA1162-G
(325,475,570,715B,720B,720BZ,720EE,720EG)
Q506 8-729-422-27 TRANSISTOR 2SD601A-Q
(325,475,570,715B,720B,720BZ,720EE,720EG)
Q540 8-729-421-19 TRANSISTOR UN2213
Q541 8-729-901-06 TRANSISTOR DTA144EK
Q542 8-729-216-22 TRANSISTOR 2SA1162-G
Q571 8-729-422-27 TRANSISTOR 2SD601A-Q
(570EG,715B,717VC,720,725)
Q702 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q703 8-729-216-22 TRANSISTOR 2SA1162-G
Q704 8-729-421-19 TRANSISTOR UN2213
Q705 8-729-216-22 TRANSISTOR 2SA1162-G
Q707 8-729-173-38 TRANSISTOR 2SA733-K
Q708 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q709 8-729-421-19 TRANSISTOR UN2213
Q710 8-729-216-22 TRANSISTOR 2SA1162-G
Q730 8-729-027-56 TRANSISTOR DTC143TKA-T146
(715B,717VC,720,725)
Q731 8-729-027-56 TRANSISTOR DTC143TKA-T146
(715B,717VC,720,725)
Q850 8-729-216-22 TRANSISTOR 2SA1162-G
(EXCEPT 570EE,720EE)
Q930 8-729-421-19 TRANSISTOR UN2213
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
Q931 8-729-421-19 TRANSISTOR UN2213
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
Q932 8-729-216-22 TRANSISTOR 2SA1162-G
(715B,717VC,720B,720BZ,720NP,720VC)
< RESISTOR >
R100 1-249-400-11 CARBON 39 5% 1/4W F
R101 1-249-400-11 CARBON 39 5% 1/4W F
R102 1-249-421-11 CARBON 2.2K 5% 1/4W F
R103 1-216-107-00 METAL CHIP 270K 5% 1/10W
R104 1-247-889-00 CARBON 270K 5% 1/4W
MA-286
Note : The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
