Sony SS-CHP7 - Electrical Parts List - Panel Board Components (Continued); Panel Board Capacitors, Connectors, Diodes; Panel Board ICs and Jacks

61
HCD-HP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C617 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C618 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C619 1-128-551-11 ELECT 22uF 20.00% 25V
C620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C621 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C635 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C636 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C637 1-124-257-00 ELECT 2.2uF 20% 50V
C639 1-119-772-91 ELECT 47uF 20.00% 35V
C640 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C641 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C642 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C643 1-115-156-11 CERAMIC CHIP 1uF 10V
C646 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C647 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C648 1-124-257-00 ELECT 2.2uF 20% 50V
C649 1-124-234-00 ELECT 22uF 20% 16V
C650 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN601 1-784-759-11 CONNECTOR,FFC 37P
CN602 1-784-731-11 CONNECTOR,FFC 9P
< DIODE >
D606 8-719-988-61 DIODE 1SS355TE-17 (TH)
D607 8-719-988-61 DIODE 1SS355TE-17 (KR,AUS)
D608 8-719-988-61 DIODE 1SS355TE-17 (US,CND,E2,KR,MX,AUS)
D609 8-719-988-61 DIODE 1SS355TE-17 (US,CND,AEP,UK,RU)
D615 8-719-988-61 DIODE 1SS355TE-17
D616 8-719-988-61 DIODE 1SS355TE-17
D617 8-719-988-61 DIODE 1SS355TE-17
D619 8-719-988-61 DIODE 1SS355TE-17
D620 8-719-988-61 DIODE 1SS355TE-17
D621 8-719-988-61 DIODE 1SS355TE-17
D622 8-719-988-61 DIODE 1SS355TE-17
D623 8-719-988-61 DIODE 1SS355TE-17
D624 8-719-988-61 DIODE 1SS355TE-17
D625 8-719-988-61 DIODE 1SS355TE-17
D626 8-719-083-61 DIODE UDZSTE-1711B
(E2,E3,KR,TW,TH,MX,AUS)
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0uH
FB602 1-550-907-21 FERRITE 0uH
FB603 1-550-907-21 FERRITE 0uH
FB604 1-550-907-21 FERRITE 0uH
FB605 1-550-907-21 FERRITE 0uH
< FLUORESCENT INDICATOR TUBE >
FLD601 1-518-923-11 INDICATOR TUBE,FLUORESCENT
< IC >
IC601 6-803-002-01 IC LC876796B-51K7-E
IC602 6-704-045-01 IC MM1574A
IC603 8-759-533-04 IC M62703ML-E1
< JACK >
JK601 1-691-293-21 JACK (PHONES)
< JUMPER RESISTOR >
JR605 1-216-864-11 METAL CHIP 0 5% 1/10W
(EXCEPT AEP,UK,RU)
JR606 1-216-864-11 METAL CHIP 0 5% 1/10W
(EXCEPT AEP,UK,RU)
JR607 1-216-864-11 METAL CHIP 0 5% 1/10W
< DIODE >
LED607 6-500-414-01 DIODE HL-30105Q2AT (DISC 1)
LED608 6-500-414-01 DIODE HL-30105Q2AT (DISC 2)
LED609 6-500-414-01 DIODE HL-30105Q2AT (DISC 3)
LED610 6-500-414-01 DIODE HL-30105Q2AT (DISC 4)
LED611 6-500-414-01 DIODE HL-30105Q2AT (DISC 5)
LED614 6-500-415-01 DIODE HL-30105Q2IT (@/1)
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q609 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q610 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
< RESISTOR >
R030 1-216-809-11 METAL CHIP 100 5% 1/10W
R031 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R032 1-216-848-11 METAL CHIP 180K 5% 1/10W
R034 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R035 1-216-841-11 METAL CHIP 47K 5% 1/10W
R036 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R037 1-216-817-11 METAL CHIP 470 5% 1/10W
R053 1-216-841-11 METAL CHIP 47K 5% 1/10W
R054 1-216-841-11 METAL CHIP 47K 5% 1/10W
R055 1-216-841-11 METAL CHIP 47K 5% 1/10W
R056 1-216-841-11 METAL CHIP 47K 5% 1/10W
R057 1-216-841-11 METAL CHIP 47K 5% 1/10W
R058 1-216-841-11 METAL CHIP 47K 5% 1/10W
R059 1-216-841-11 METAL CHIP 47K 5% 1/10W
R060 1-216-841-11 METAL CHIP 47K 5% 1/10W
R061 1-216-841-11 METAL CHIP 47K 5% 1/10W
R062 1-216-841-11 METAL CHIP 47K 5% 1/10W
R063 1-216-841-11 METAL CHIP 47K 5% 1/10W
R064 1-216-841-11 METAL CHIP 47K 5% 1/10W
R065 1-216-841-11 METAL CHIP 47K 5% 1/10W
R066 1-216-841-11 METAL CHIP 47K 5% 1/10W
R067 1-216-841-11 METAL CHIP 47K 5% 1/10W
R068 1-216-841-11 METAL CHIP 47K 5% 1/10W
R069 1-216-841-11 METAL CHIP 47K 5% 1/10W
R070 1-216-841-11 METAL CHIP 47K 5% 1/10W
R071 1-216-841-11 METAL CHIP 47K 5% 1/10W
R072 1-216-841-11 METAL CHIP 47K 5% 1/10W
R073 1-216-841-11 METAL CHIP 47K 5% 1/10W
R074 1-216-841-11 METAL CHIP 47K 5% 1/10W
R075 1-216-841-11 METAL CHIP 47K 5% 1/10W
R076 1-216-841-11 METAL CHIP 47K 5% 1/10W
R077 1-216-841-11 METAL CHIP 47K 5% 1/10W
R078 1-216-841-11 METAL CHIP 47K 5% 1/10W
R079 1-216-841-11 METAL CHIP 47K 5% 1/10W
R080 1-216-841-11 METAL CHIP 47K 5% 1/10W
R081 1-216-841-11 METAL CHIP 47K 5% 1/10W
R082 1-216-841-11 METAL CHIP 47K 5% 1/10W
PANEL
