SURROUND
2)
:
130 W + 130 W
3)
120W + 120W
4)
SURROUND BACK
2)
:
130 W + 130 W
3)
120W + 120W
4)
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 120 V AC, 60 Hz (in USA
and Canada), 230 V AC, 50/60 Hz (in Europe
and general area)
3)
USA/Canadian model
4)
European model
Frequency response
Inputs (Analog)
Inputs (Digital)
Outputs
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Tuning range
Intermediate frequency
450 kHz
Antenna (aerial) Loop antenna (aerial)
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 × 480p@60 Hz
720 × 480p@59.94/60 Hz
1280 × 720p@59.94/60 Hz
1920 × 1080i@59.94/60 Hz
1920 × 1080p@59.94/60 Hz
720 × 576p@50 Hz
1280 × 720p@50 Hz
1920 × 1080i@50 Hz
PHONO RIAA equalization
curve ± 1.0 dB (20 Hz –
20 kHz)
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE, MD, TV,
VIDEO 1/2, BD, DVD,
SAT/CATV
10 Hz – 100 kHz
± 3 dB
PHONO Sensitivity: 2.5 mV
Impedance: 50 kohms
S/N: 90 dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE, MD, TV,
VIDEO 1/2, BD, DVD,
SAT/CATV
Sensitivity: 150 mV
Impedance: 50 kohms
S/N: 100 dB (A,
20 kHz LPF)
BD, DVD,
SA-CD/CD (Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
VIDEO 1/2, TV, SAT/
CATV, TAPE, MD
(Optical)
S/N: 96 dB
(A, 20 kHz LPF)
TAPE (REC OUT),
VIDEO 1, ZONE 2,
ZONE 3 (AUDIO OUT)
Voltage:150 mV
Impedance: 1 kohm
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R ,
FRONT HIGH L/R,
SUBWOOFER
Voltage: 2 V
Impedance: 1 kohm
Area Tuning scale
10 kHz step 9 kHz step
USA, Canada 530 –
1,710 kHz
531 –
1,710 kHz
Europe – 531 –
1,602 kHz
