1 Rotate INPUT SELECTOR to select the
input.
The selected input appears in the display.
2 Turn on the component and start
playback.
3 Rotate MASTER VOLUME –/+ to adjust
the volume.
To mute the sound
Press MUTING on the remote.
Notes on using headphones
• When headphones are connected, you can select only
the following sound fields (page 32).
– HEADPHONE (2CH)
– HEADPHONE THEATER
• When headphones are connected and you use the
MULTI CH IN function (see “Listening to multi
channel sound”), the sound of all channels may not
output depending on the speaker settings.
You can select the audio directly from the
components connected to the MULTI CH IN
jacks. This enables you to enjoy high quality
analog inputs like DVD or Super Audio CD.
Also see “D.PWR” (page 38).
Surround effects are not activated when using
this input.
Press MULTI CH IN.
When a center speaker or sub
woofer is not connected
If you have set the center speaker to “NO” or
“MIX”, or set the sub woofer to “NO” in the SP
SETUP menu (page 17), and you activate the
MULTI CH IN function, the analog center or
sub woofer audio will be output from the front
left and right speakers.
When MULTI CHANNEL
DECODING indicator lights up
The MULTI CHANNEL DECODING indicator
lights up when the receiver is decoding multi
channel sources.
However, this indicator does not light up if you
select 2CH STEREO mode.
Amplifier Operation
Selecting the component
To select the Display
VCR VIDEO 1 or
VIDEO 2
Camcorder or TV game VIDEO 3
DVD player DVD
Satellite tuner TV/SAT
MD or tape deck MD/TAPE
CD or Super Audio CD
player
SA-CD/CD
Built-in tuner (FM) Tuner (FM)
Built-in tuner (AM) Tuner (AM)
Turntable PHONO
Listening to multi channel
sound
— MULTI CH IN
