x SP > XXX Hz
(Speaker crossover frequency)
Initial setting: 100 Hz
Lets you set the bass crossover frequency of speakers
set to “SMALL” in the SP SETUP menu. You can
adjust the bass crossover frequency in three steps
(60 Hz, 100 Hz and 150 Hz).
Advanced LEVEL menu
parameters
When “MENU” is set to “MENU EXP.”, all of
the following parameters are displayed and
adjustable.
See page 35 for the LEVEL menu adjustments.
Initial settings are underlined.
All LEVEL menu parameters
* Adjustable only when “MENU” is set to “MENU
EXP.”
** Adjustable only when surround back speaker is set
to “DUAL” (page 18).
x P.NOISE (Phase noise)
Initial setting: OFF
Lets you output the test tone sequentially from two
adjacent speakers.
x P.AUDIO (Phase audio)
Initial setting: OFF
Lets you output the front 2 channel source sound
(instead of the test tone) sequentially from adjacent
speakers.
x COMP. XXX
(Dynamic range compressor)
Lets you compress the dynamic range of the sound
track. This may be useful when you want to watch
movies at low volumes late at night.
•OFF
The dynamic range is not compressed.
•STD
The dynamic range is compressed as intended by the
recording engineer.
•MAX
The dynamic range is compressed dramatically.
Tip
Dynamic range compressor lets you compress the
dynamic range of the soundtrack based on the dynamic
range information included in the Dolby Digital signal.
We recommend using the “MAX” setting. This greatly
compresses the dynamic range and lets you view
movies late at night at low volumes. Unlike analog
limiters, the levels are predetermined and provide a
very natural compression.
Note
Dynamic range compression is possible with Dolby
Digital sources only.
T.TONE
P.NOISE*
P.AUDIO*
BAL. XXXX
CTR XXX.X dB
SUR.L. XXX.X dB
SUR.R. XXX.X dB
SB XXX.X dB
SBL XXX.X dB**
SBR XXX.X dB**
S.W. XXX.X dB
S.W. XXX dB
COMP. XXX*
EFCT. XXX
MULTI CH IN
D.RANGE
D.RANGE

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
