Remote
Button
Operations Function
TOP MENU/ DVD player Displays DVD title.
GUIDE rs Satellite tuner Displays guide menu.
TUNER e; Receiver To listen to radio
programs.
TV CH +/–
r;
TV Selects preset TV
channels.
TV/SAT t; Receiver To watch TV
programs or satellite
receiver.
TV/VIDEO
ek
TV Selects input signal:
TV input or video
input.
TV VOL
+/– ra
TV Adjusts the volume of
the TV.
TV ?/1 td TV Turns the TV on or
off.
VIDEO1 ta Receiver To watch VCR.
(VTR mode 3)
VIDEO2 ts Receiver To watch VCR.
(VTR mode 1)
VIDEO3 wk Receiver To watch VCR.
(VTR mode 2)
WIDE el TV Selects the wide
picture mode.
1-9 and
0/10 rh
Receiver Use with SHIFT to
preset radio station or
tuning to preset
stations and with
D.TUNING for direct
tuning.
CD player/
VCD player/
LD player/
MD deck/
DAT deck
Selects track
numbers.
0/10 selects track 10.
TV/VCR/
Satellite tuner
Selects channel
numbers.
2CH rk Receiver Selects 2CH
STEREO mode.
>10/11 ef CD player/
VCD player/
LD player/
MD deck
Selects track numbers
over 10.
-/-- q; TV Selects the channel
entry mode, either one
or two digit.
Remote
Button
Operations Function
?/1 wj Receiver Turns the receiver on
or off.
./>
rg ef
VCR/
CD player/
VCD player/
LD player/
DVD player/
MD deck/
DAT deck/
Tape deck
Skips tracks.
m/M
rf
CD player/
VCD player/
DVD player
LD player/
MD deck
Searches tracks in the
forward or backward
direction.
VCR/
DAT deck/
Tape deck
Fastforwards or
rewinds.
N rd VCR/
CD player/
VCD player/
LD player/
DVD player/
MD deck/
DAT deck/
Tape deck
Starts playback.
X eg VCR/
CD player/
VCD player/
LD player/
DVD player/
MD deck/
DAT deck/
Tape deck
Pauses playback or
recording. (Also starts
recording with
components in
recording standby.)
x eh VCR/
CD player/
VCD player/
LD player/
DVD player/
MD deck/
DAT deck/
Tape deck
Stops playback.
O ej VCD player/
LD player/
DVD player
Returns to the
previous menu or
exits the menu.
V/v qh Receiver Selects a menu item.
B/b qh Receiver Adjusts or changes
the setting.
V/v/B/b qh VCR/
Satellite tuner/
DVD player
Selects a menu item.

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
