Additional Information
Main unit
DIRECT qa (23)
DISPLAY 6 (20, 44)
Display window 4 (21, 22)
INPUT MODE 5 (28)
INPUT SELECTOR 7
(16, 17, 18, 19)
MULTI CH IN qs (17)
PHONES jack qg (43)
POWER (power) switch 2
(11, 12, 15)
PRESET TUNING +/– qf (18)
SOUND FIELD q;
(23, 24, 25, 43, 44)
STANDBY indicator 3
SURROUND BACK
DECODING qd (30)
VOLUME 8 (15, 17, 43)
(remote sensor) 1 (44)
2CH 9 (11, 23, 25)
List of button locations and reference pages
