61
STR-DB900
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q917 8-729-271-31 TRANSISTOR 2SC2713-G
Q920 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R901 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R903 1-249-528-91 CARBON 100 5% 1/4W
R904 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
0 R905 1-244-317-71 METAL 0.18 5% 2W
0 R906 1-244-317-71 METAL 0.18 5% 2W
0 R907 1-219-237-11 SOLID 3.3M 20% 1/2W
0 R908 1-244-317-71 METAL 0.18 5% 2W
R909 1-216-819-11 METAL CHIP 680 5% 1/10W
0 R910 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R911 1-215-904-61 METAL OXIDE 100K 5% 2W
R912 1-245-261-31 METAL OXIDE 0.12 5% 2W
R913 1-245-261-31 METAL OXIDE 0.12 5% 2W
R914 1-245-261-31 METAL OXIDE 0.12 5% 2W
0 R915 1-249-564-31 CARBON 3.3K 5% 1/4W
R916 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R917 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R918 1-215-889-61 METAL OXIDE 330 5% 2W
R919 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R920 1-215-880-31 METAL OXIDE 10 5% 2W
0 R921 1-249-568-31 CARBON 4.7K 5% 1/4W
0 R922 1-245-428-11 METAL OXIDE 150K 5% 2W
0 R923 1-249-504-31 CARBON 10 5% 1/4W
0 R924 1-249-552-91 CARBON 1K 5% 1/4W
R925 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R926 1-218-644-11 METAL CHIP 10 0.5% 1/10W
R927 1-249-556-31 CARBON 1.5K 5% 1/4W
R928 1-249-556-31 CARBON 1.5K 5% 1/4W
R929 1-216-820-11 METAL CHIP 820 5% 1/10W
R930 1-216-812-11 METAL CHIP 180 5% 1/10W
R931 1-249-556-31 CARBON 1.5K 5% 1/4W
R932 1-249-556-31 CARBON 1.5K 5% 1/4W
R933 1-216-819-11 METAL CHIP 680 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R937 1-216-821-11 METAL CHIP 1K 5% 1/10W
R941 1-249-588-91 CARBON 33K 5% 1/4W
R946 1-218-692-11 METAL CHIP 1K 0.5% 1/10W
R947 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R951 1-216-837-11 METAL CHIP 22K 5% 1/10W
R952 1-218-716-11 METAL CHIP 10K 0.5% 1/10W
R954 1-216-841-11 METAL CHIP 47K 5% 1/10W
R955 1-216-819-11 METAL CHIP 680 5% 1/10W
R956 1-216-833-11 METAL CHIP 10K 5% 1/10W
R957 1-216-839-11 METAL CHIP 33K 5% 1/10W
0 R958 1-216-847-11 METAL CHIP 150K 5% 1/10W
R960 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R961 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R962 1-216-833-11 METAL CHIP 10K 5% 1/10W
R963 1-216-821-11 METAL CHIP 1K 5% 1/10W
R964 1-218-720-11 METAL CHIP 15K 0.5% 1/10W
R965 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R966 1-218-703-11 METAL CHIP 3K 0.5% 1/10W
R967 1-216-853-11 METAL CHIP 470K 5% 1/10W
< TRANSFORMER >
0T901 1-443-474-11 TRANSFORMER, DC CONVERTER
T902 1-439-868-11 TRANSFORMER, DC CONVERTER
< THERMISTOR >
0TH901 1-803-916-11 THERMISTOR, NTC
************************************************************
REG BOARD
**********
< CAPACITOR >
C990 1-135-770-91 ELECT 47uF 63V
< CONNECTOR >
* CN990 1-566-693-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN991 1-564-214-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D990 6-500-522-31 DIODE 10EDB40-TB5
< TRANSISTOR >
Q990 8-749-010-43 IC NEN250
< RESISTOR >
R990 1-249-560-31 CARBON 2.2K 5% 1/4W
R991 1-249-604-31 CARBON 150K 5% 1/4W
R992 1-249-405-11 CARBON 100 5% 1/4W
R993 1-249-405-11 CARBON 100 5% 1/4W
************************************************************
VIDEO BOARD
***********
< CAPACITOR >
C703 1-126-916-11 ELECT 1000uF 20% 6.3V
C704 1-126-960-11 ELECT 1uF 20% 50V
C705 1-126-960-11 ELECT 1uF 20% 50V
C706 1-126-960-11 ELECT 1uF 20% 50V
C707 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C708 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C709 1-126-968-11 ELECT 100uF 20% 50V
C710 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN701 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC701 8-759-474-37 IC NJM2279M-TE2
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
REGPOWER VIDEO
